NPM–W2 EJM7DE-MB-02-1T-00
Motor Number Error
Reset Process Error
Servo Process Error
Motor Object Not Exist
Nozzle shaft drop
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Nozzle shaft may be locked
at the lowered position.
(Nozzle shaft drop error
occurred.)
Do not move the head in X/Y
direction. Raise the nozzle shaft by
hand.
1521
Servo driver of the target axis
is at fault.
(No motor object.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1523
Servo driver of the target axis
is at fault.
(Servo process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1524
Servo driver of the target axis
is at fault.
(Reset process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1525
Servo driver of the target axis
is at fault.
(Motor number error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1526
2-1-4-26
NPM–W2 EJM7DE-MB-02-1T-00
Position Error Interrupt
Exclusive Process Error
Return To Origin Process
Error
Motion Process Error
Motion Preparation Error
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
14
Error Code
Error Message
Cause Inspection and Solution
Servo driver of the target axis
is at fault.
(Operation preparation error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1528
Servo driver of the target axis
is at fault.
(Operation process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1529
Servo driver^ motor or origin
sensor of the target axis is at
fault.
(Origin return process error
occurred)
Check the situation of the error
occurred and error message, and
contact PFSC.
1530
Servo driver of the target axis
is at fault.
(Exclusive process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1531
Unwanted interrupt occurred
during positioning of X/Y
axes.
(Position interrupt error
occurred.)
1) Restart the machine.
2) If the error persists, contact PFSC.
1540
2-1-4-27
NPM–W2 EJM7DE-MB-02-1T-00
Data Set Command Not
Issued Error
Write EEPROM Error
Servo Ready Off
Completion Error Interrupt
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Unwanted interrupt occurred
during positioning of X/Y
axes.
(Completion interrupt error
occurred)
1) Restart the machine.
2) If the error persists, contact PFSC.
1542
Axis movement failed
because it was attempted
without the communication
with the servo amplifier
established.
(Servo ready OFF error
occurred.)
Restart the machine.If the error
persists even after the machine is
restarted, contact PFSC.
1543
Wiring between the main
controller and servo amplifier
may be broken.
(Writing to EEPROM in servo
amplifier failed to finish
properly.)
Make sure the wiring between the
main controller and servo amplifier
is not broken.
1545
Improper procedure was
taken in software processing.
(Axis movement failed due to
incorrect data of the
applicable axis (mismatch of
data combination).)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1546
2-1-4-28
