NPM–W 2 EJM7DE-MB-02 -1T-00 16-nozzle hea d Z PCB Voltage Error Carry In Again Production Start Error(STOP) Carry In Again Production Start Error(END) Error Message Troubleshooting 2-1-2 Self-dia gnosis er r or s 18 Erro…
NPM–W2 EJM7DE-MB-02-1T-00
LNB Production Start Error
LNB Communication
Abnormality
Chip Thickness Sensor
Unmatched Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Mismatch between the frame
and chip thickness sensor
(Self-diagnosis error
occurred.)
Make sure the chip thickness sensor
that matches the frame is installed.
40105
Communication disabled due
to broken wires in the
communication system or
trouble like hub power OFF
(Self-diagnosis error
occurred.)
Check the communication system
and the power to the hub is
ON.When the simplified LNB is
used, check if the power to the
simplified LNB computer is ON. To
restart the LNB conveyor or
simplified LNB computer when the
machine is running, engage all the
machines in the cycle stop mode or
restart the machine from the main
menu.
40106
Machine is not ready for
production with the PanaCIM
or customer's system.
(Self-diagnosis error
occurred.)
Enable production with the PanaCIM
or customer's system.
40107
2-1-2-34
NPM–W2 EJM7DE-MB-02-1T-00
16-nozzle head Z PCB
Voltage Error
Carry In Again Production
Start Error(STOP)
Carry In Again Production
Start Error(END)
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 18
Error Code
Error Message
Cause Inspection and Solution
There is no PCB to be
reloaded on the reloading
conveyor.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Read the barcode information of
the PCB to be reloaded and put it
on the reloading conveyor.
2) If the error persists even after the
PCB is placed, the reloading
conveyor may be at fault.Contact
PFSC.
40108
There are PCBs on the
reload conveyor.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Remove the PCB from the
reloading conveyor.
2) If the error persists even after the
PCB is removed, the reloading
conveyor may be at fault.Contact
PFSC.
40109
Voltage at the 16-nozzle
mount head Z-axis control
board has dropped
abnormally.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40110
2-1-2-35
NPM–W2 EJM7DE-MB-02-1T-00
16-Nozzle HeadθPCB
Fuse Disconnection
16-Nozzle HeadθPCB
Temperature Error
16-Nozzle Head θPCB
Voltage Error
16-Nozzle Head Z PCB
Fuse Disconnection
16-Nozzle Head Z PCB
Temperature Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
CPU temperature at the 16-
nozzle mount head Z-axis
control board has exceeded
the setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40111
Fuse of the 16-nozzle mount
head Z-axis control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40112
Voltage at the 16-nozzle
mount head θ-axis control
board has dropped
abnormally.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40113
CPU temperature at the 16-
nozzle mount head θ-axis
control board has exceeded
the setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40114
Fuse of the 16-nozzle mount
head θ-axis control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40115
2-1-2-36
