NPM–W 2 EJM7DE-MB-02 -1T-00 Bad Nozzle Detect Part Mount Error Solutions to errors Error Code Error Message Cause Inspection and Solution Any of the following causes is likely: 1) Comp onent was carried back without moun…

NPM–W2 EJM7DE-MB-02-1T-00

Parts Standing Error

Parts Recognition Error

Error

Message

Troubleshooting

2-1-3

Single stop error 2

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Improper components are

set.

2) Incorrect component data

(component dimensions^

etc.)

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Set the correct components.

2) Check the component data

(component dimensions, etc.).

40307

Any of the following causes

is likely:

1) Improper components are

set.

2) Incorrect component data

(component dimensions^

etc.)

3) Component picked up

sideways.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Set the correct components.

2) Check the component data

(component dimensions, etc.).

3) Check the pickup condition.

40308

2-1-3-2

NPM–W2 EJM7DE-MB-02-1T-00

Bad Nozzle Detect

Part Mount Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Component was carried

back without mounting it.

2) Nozzle or filter is clogged

with dust or dirt.

3) Sensor may be at fault.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Remove the remaining

components from the nozzles and

restart the machine.

2) Clean the nozzle and filter.

3) Choose [Machine] - [Adjust] -

[Head] - [Vac output check] and if

any problem is found, contact

PFSC.

40309

Pickup or recognition error

occurs frequently at a

specific nozzle.

(Single stop error occurred.)

Choose [Machine] - [Set] - [Head] -

[Bad head] and identify the cause

(pickup error or recognition error).

Then perform appropriate

maintenance.

40310

2-1-3-3

NPM–W2 EJM7DE-MB-02-1T-00

Feeder Error Rate Over

Bad Nozzle Rate Over

Error

Message

Troubleshooting

2-1-3

Single stop error 3

Error Code

Error Message

Cause Inspection and Solution

No. of bad nozzles has

exceeded the preset count.

(Single stop error occurred.)

Take any of the following measures:

1) Choose [Machine] - [Set] - [Head]

- [Action Parameter] and make

sure the judgment value is correct.

2) Choose [Machine] - [Set] - [Head]

- [Bad head] and identify the cause

(pickup error or recognition error).

Then perform appropriate

maintenance and reset the setting

of bad nozzles.

40311

Pickup error rate for the

feeder has exceeded the

setting value.

(Single stop error occurred.)

Take any of the following measures:

1) Make sure the tape is not

jammed.

2) Make sure the parameters of the

component data are set properly.

40312
