NPM–W2 EJM7DE-MB-02-1T-00
Middle Request ON time
out
PCB Motion Error
Conv over run sensor
abnormally
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Sensor did not turn ON in
back movement due to
overrun detection when
loading PCB.
(Error occurred in overrun
sensor when loading PCB.)
Check the PCB on the conveyor and
condition of the PCB sensor.
44005
Stop position sensor turned
OFF in back movement due
to overrun detection when
loading PCB.
(PCB positioning error
occurred when loading
PCB.)
Check the PCB on the conveyor and
condition of the PCB sensor.
44006
PCB request signal from
next process machine failed
to turn ON during middle
standby transfer between
machines.
(Timeout error occurred
during middle standby
transfer between machines.)
Take any of the following measures:
1) Check the status of
synchronization and middle
standby confirmation signals
between the machines.
2) Check the situation of the error
occurred and contact PFSC.
44007
2-1-3-91
NPM–W2 EJM7DE-MB-02-1T-00
PCB Info Communication
Error
PCB Info transfer Error
Error
Message
Troubleshooting
2-1-3
Single stop error 47
Error Code
Error Message
Cause Inspection and Solution
Error occurred while
transferring PCB information
during PCB transfer.
(Error occurred during
transfer of PCB information.)
Take any of the following measures:
1) Check the position of PCB on the
conveyor.
2) Check the setting of
communication between machines.
3) Check the situation of the error
occurred and contact PFSC.
44008
Timeout occurred while
waiting for transferring PCB
information during PCB
unloading.
(Error occurred in
communication of PCB
information.)
Take any of the following measures:
1) Check the position of PCB on the
conveyor.
2) Check the setting of
communication between machines.
3) Check the situation of the error
occurred and contact PFSC.
44009
2-1-3-92
NPM–W2 EJM7DE-MB-02-1T-00
LNB Command Send
Error
PCB Info Confirm Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Failed to check PCB
information during PCB
transfer.
(Error occurred during PCB
information check.)
Take any of the following measures:
1) Check the position of PCB on the
conveyor.
2) Check the setting of
communication between machines.
3) Check the situation of the error
occurred and contact PFSC.
44010
Transmission error occurred
while requesting for reading
external PCB barcode.
(Error occurred in
transferring command to
LNB.)
Take any of the following measures:
1) Check the communication
between the LNB and machine.
2) Check the setting of
communication between machines.
3) Check the situation of the error
occurred and contact PFSC.
44011
2-1-3-93
