NPM–W2 EJM7DE-MB-02-1T-00
Host Feeder Time Out
Feeder Setting Error
Mount Pos Teach Ope.
Err
Servo Off Error
Error
Message
Troubleshooting
2-1-3
Single stop error 11
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Axis movement is
disabled because the servo
switch is OFF.
2) Axis movement is
disabled because interlock
is engaged in the adjoining
machine.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check the
condition of the servo switch and
contact PFSC.
2) Release the interlock of the
adjoining machine.
40362
Teaching started with the
setting that does not match
the operating condition for
teaching. Or teaching
condition cannot be met due
to error during teaching.
(Single stop error occurred.)
Reset the tray counter. Eliminate
the cause if recognition or pickup
error has occurred. Reset the bad
head setting.
40363
Failed to make feeder setting.
(Single stop error occurred.)
Make sure the attached feeder is
correct. If something is wrong with
the feeder, replace it with a proper
one.
40364
Timeout occurred during
waiting for completion of
preparation for pickup by
host feeder.
(Single stop error occurred.)
Check the feeder.
40365
2-1-3-20
NPM–W2 EJM7DE-MB-02-1T-00
Stamp Unit Cover Open
Stamp Material Leak Err
Machine File Name
Mismatch
Changeover Cart
Unconnected
Feeder Abnormality
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Abnormality found in the
feeder.
(Single stop error occurred.)
Check the feeder.
40366
Feeder cart connector not
connected.
(Single stop error occurred.)
Connect the feeder cart
again.Choose [Machine] - [Adjust] -
[All] - [Input confirm] and check the
connection of feeder cart. If any
problem is found, contact PFSC.
40367
Production data may not
agree with that of the
preceding machine.
(Single stop error occurred.)
Download the production data again.
40368
Transcript material is spilling.
(Single stop error occurred.)
Check the transcript feeder.
40369
Transcript unit cover is open.
(Single stop error occurred.)
Close the transcript unit cover.
40370
2-1-3-21
NPM–W2 EJM7DE-MB-02-1T-00
Nozzle Diameter Error
Nozzle Position Error
Feeder Error Rate Over
Error
Message
Troubleshooting
2-1-3
Single stop error 12
Error Code
Error Message
Cause Inspection and Solution
Machine stopped since the
tape feeder error rate
((Pickup error count +
Recognition error count) /
Pickup count) of the feeder
concerned has exceeded the
specified limit.
(Single stop error occurred.)
Take any of the following measures:
1) Make sure the judgment criteria
value is correct on the bad
judgment value screen of the
machine parameter.
2) Choose [Prod. info.] - [Pickup
info.] and identify the cause
(pickup error or recognition error).
Then perform appropriate
maintenance and clear the setting
of the bad nozzle.
40371
Nozzle position was judged
to be abnormal during nozzle
position recognition.
(Single stop error occurred.)
Check the nozzles are free of bend
or other defects.
40372
Nozzle diameter was judged
to be abnormal during nozzle
position recognition.
(Single stop error occurred.)
Make sure that correct nozzles are
attached.
40373
2-1-3-22
