NPM–W 2 EJM7DE-MB-02 -1T-00 Momentary Power OFF Cover O pen (Rear Side Safety switch interior side) Cover O pen (Front Side Safety switch interior side) Error Message Troubleshooting 2-1-4 Emer genc y stop er r or s 2 Er…
NPM–W2 EJM7DE-MB-02-1T-00
Safety Device Detect
(Post Proc)
Safety Device Detect
(Pre Proc)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Adjoining machine in the
previous process has been
turned OFF or emergency
stop switch has been
pressed.
(Interlock occurred.)
Take any of the following measures:
1) Turn ON power if the main switch
of the adjoining machine in the
previous process is OFF.
2) Reset the emergency stop switch
of the adjoining machine in the
previous machine if pressed.
1304
Adjoining machine in the
next process has been
turned OFF or emergency
stop switch has been
pressed.
(Interlock occurred.)
Take any of the following measures:
1) Turn ON power if the main switch
of the adjoining machine in the
next process is OFF.
2) Reset the emergency stop switch
of the adjoining machine in the
next process machine if pressed.
1305
2-1-4-2
NPM–W2 EJM7DE-MB-02-1T-00
Momentary Power OFF
Cover Open
(Rear Side Safety switch
interior side)
Cover Open
(Front Side Safety switch
interior side)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
2
Error Code
Error Message
Cause Inspection and Solution
Safety cover is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
1306
Safety cover is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
1307
Power supply may have
been stopped momentarily
due to power failure.
(Interlock occurred.)
Check the voltage of the power
supply in the plant. Turn the
machine power back ON and start
production. If the error persists,
contact PFSC.
1308
2-1-4-3
NPM–W2 EJM7DE-MB-02-1T-00
Conveyor opening Sensor
Detect
(Right)
Conveyor opening Sensor
Detect
(Left)
Emergency Stop Switch
ON
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Emergency stop switch has
been pressed.
(Interlock occurred.)
Take measures in the following
order.
1) Turn the emergency stop switch
clockwise to reset.(One position
each at front and rear)
2) If the machine fails to be restored
even after resetting the emergency
stop switch, the switch may be
broken.Contact PFSC.
1309
Transfer opening sensor
(Left) is OFF.
(Interlock occurred.)
Check the condition of the adjoining
machine on the left.Choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check the condition of
the transfer opening sensor (Left).
1310
Transfer opening sensor
(Right) is OFF.
(Interlock occurred.)
Check the condition of the adjoining
machine on the right.Choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check the condition of
the transfer opening sensor (Right).
1311
2-1-4-4
