NPM–W2 EJM7DE-MB-02-1T-00
Tape Float
Driver Software Interlock
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
13
Error Code
Error Message
Cause Inspection and Solution
Servo driver of the target axis
is at fault.
(Driver software interlock
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1513
The tape cover sensor is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the top tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensors 1 to 4 of
the table are OFF when the light
from the emitter is blocked and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1520
2-1-4-25
NPM–W2 EJM7DE-MB-02-1T-00
Motor Number Error
Reset Process Error
Servo Process Error
Motor Object Not Exist
Nozzle shaft drop
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Nozzle shaft may be locked
at the lowered position.
(Nozzle shaft drop error
occurred.)
Do not move the head in X/Y
direction. Raise the nozzle shaft by
hand.
1521
Servo driver of the target axis
is at fault.
(No motor object.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1523
Servo driver of the target axis
is at fault.
(Servo process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1524
Servo driver of the target axis
is at fault.
(Reset process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1525
Servo driver of the target axis
is at fault.
(Motor number error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1526
2-1-4-26
NPM–W2 EJM7DE-MB-02-1T-00
Position Error Interrupt
Exclusive Process Error
Return To Origin Process
Error
Motion Process Error
Motion Preparation Error
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
14
Error Code
Error Message
Cause Inspection and Solution
Servo driver of the target axis
is at fault.
(Operation preparation error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1528
Servo driver of the target axis
is at fault.
(Operation process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1529
Servo driver^ motor or origin
sensor of the target axis is at
fault.
(Origin return process error
occurred)
Check the situation of the error
occurred and error message, and
contact PFSC.
1530
Servo driver of the target axis
is at fault.
(Exclusive process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1531
Unwanted interrupt occurred
during positioning of X/Y
axes.
(Position interrupt error
occurred.)
1) Restart the machine.
2) If the error persists, contact PFSC.
1540
2-1-4-27
