NPM-W2 EJM7DE-MB-04T-00
Load lists
Motor list 1
Troubleshooting
4-2-1
Standard unit
Unit name No. Name
Location Remark
Main body M501
X-axis motor
Front
M502
M506
Y-axis motor Front
M503
X-axis motor
Rear
M504
M508
Y-axis motor Rear
G103
Cooling fan
Front
G104
Cooling fan
Rear
G111 Machine inner cooling fan
G201 Vacuum pump Rear
Single conveyor
M601
Lane 1 Transfer motor Left waiting (Fixed
side)
M602
Lane 1 Transfer motor Placement position 2
(Fixed side)
M603
Lane 1 Transfer motor Placement position 1
(Fixed side)
M604
Lane 1 Transfer motor Right waiting (Fixed
side)
M605
Lane 1 Transfer motor Left waiting (Movable
side)
M606
Lane 1 Transfer motor Placement position 2
(Movable side)
M607
Lane 1 Transfer motor Placement position 1
(Movable side)
M608
Lane 1 Transfer motor Right waiting
(Movable side)
M609 Lane 1 Width-adjustment motor
Dual conveyor
M601
Lane 1 Transfer motor Left waiting (Fixed
side)
M602
Lane 1 Transfer motor Placement position 2
(Fixed side)
M603
Lane 1 Transfer motor Placement position 1
(Fixed side)
M604
Lane 1 Transfer motor Right waiting (Fixed
side)
M605
Lane 1 Transfer motor Left waiting (Movable
side)
M606
Lane 1 Transfer motor Placement position 2
(Movable side)
M607
Lane 1 Transfer motor Placement position 1
(Movable side)
M608
Lane 1 Transfer motor Right waiting
(Movable side)
M609 Lane 1 Width-adjustment motor
4-2-1-1
NPM-W2 EJM7DE-MB-04T-00
Unit name No. Name
Location Remark
Dual conveyor
M631
Lane 2 Transfer motor Left waiting (Fixed
side)
M632
Lane 2 Transfer motor Placement position 2
(Fixed side)
M633
Lane 2 Transfer motor Placement position 1
(Fixed side)
M634
Lane 2 Transfer motor Right waiting (Fixed
side)
M635
Lane 2 Transfer motor Left waiting (Movable
side)
M636
Lane 2 Transfer motor Placement position 2
(Movable side)
M637
Lane 2 Transfer motor Placement position 1
(Movable side)
M638
Lane 2 Transfer motor Right waiting
(Movable side)
M639 Lane 2 Width-adjustment motor
Load arrangement
drawings
4-2-1-2
NPM-W2 EJM7DE-MB-04T-00
Unit name No. Name
Location Remark
Light weight 16-nozzle
head
M401
-axis motor 1
M402
-axis motor 2
M403 Z-axis motor 1
M404 Z-axis motor 2
M405 Z-axis motor 3
M406 Z-axis motor 4
M407 Z-axis motor 5
M408 Z-axis motor 6
M409 Z-axis motor 7
M410 Z-axis motor 8
M411 Z-axis motor 9
M412 Z-axis motor 10
M413 Z-axis motor 11
M414 Z-axis motor 12
M415 Z-axis motor 13
M416 Z-axis motor 14
M417 Z-axis motor 15
M418 Z-axis motor 16
G1001 Z-axis cooling fan motor
G1002 CPU cooling fan motor
12-nozzle head M401
-axis motor 1
M402
-axis motor 2
M403
Z-axis motor 1
M404
Z-axis motor 2
M405
Z-axis motor 3
M406
Z-axis motor 4
M407
Z-axis motor 5
M408
Z-axis motor 6
M409
Z-axis motor 7
M410
Z-axis motor 8
M411
Z-axis motor 9
M412
Z-axis motor 10
M413
Z-axis motor 11
M414
Z-axis motor 12
G1001
Z-axis cooling fan motor
G1002 CPU cooling fan motor
4-2-1-3
Option
Load lists
Motor list 2
Troubleshooting
4-2-1
