NPM-W 2 EJM7DE-MB-01T-00 Pickup error , Stand pickup (confirmation items when the pickup rate decreases) Feeder erro r 1-1-1-1 to1-1-1-2 See [Cannot picku p] Nozzle selection error 1-1-1 -2 Nozzle error Pickup c ondition…
NPM-W2 EJM7DE-MB-01T-00
Cannot pickup
Feeder error
What if
Pickup motion error
Problem Cause
Check/Solution Reference
Intelligent Tape
Feeder
Operating
Instructions
6
1-1-1-1
Component data
error
DGS
Programming
Manual 6.5.3
Pickup condition
error
Check whether the pickup
pusher has been properly set.
Adjust if necessary.
Check the vacuum pressure
(appropriate pressure: -100 to
–87kPa). If it is not within the
value, Adjust the pressure.
Check the pickup position setting.
Adjust if necessary.
Check whether too much vacuum
leaks during component pickup.
Adjust if so.
Change to the appropriate pickup
speed.
Supply unit (feeder
or tray) setting
error or defect
Maintenance
4-1-1
Operating
procedure
6-2-4,6-2-6,6-2-8
DGS
Programming
Manual 6.5.3
DGS
Programming
Manual 6.5.3
[1.]
Maintenance
5-7
[2]
Contact us.
[3.]
Operating
procedure
6-1-10
[4,5]
Operating
procedure
2-4-2
6-1-10
Troubleshooting
1-1-1
1.Check feeding motion. Adjust if
there is an error.
2.Check for dust or chip
component stuck onto the tape
pusher cover. If so, clean the
cover.
3.Check the peeling motion.
Adjust if there is an error.
1.Check whether the component
thickness has been input
properly. Adjust if necessary.
2.Check the amount of feed of the
feeder and the tape type
(paper,embossed paper) Adjust
and replace if necessary.
1.Wipe off if the feeder attachment
part is contaminated, or remove
if components are jammed.
2.Replace the cutter blade if it is
not sharp enough.
3.Adjust if the tray pickup height Is
not set properly.
4.Fix the position if the tray is
installed incorrectly.
5.Check whether the tray is
properly set on the pallet. Fix it if
necessary
‐
NPM-W2 EJM7DE-MB-01T-00
Pickup error,
Stand pickup
(confirmation
items when the
pickup rate
decreases)
Feeder error
1-1-1-1 to1-1-1-2
See [Cannot pickup]
Nozzle selection
error
1-1-1-2
Nozzle error
Pickup condition
error
Check the vacuum pressure
(appropriate pressure:-100 to
-87kPa). If it is not within the
Value, adjust the pressure.
Check the pickup position setting.
Adjust if incorrect.
1-1-1-1 to 1-1-1-2
See [Cannot pickup]
Nozzle selection
error
Check whether the appropriate
nozzle has been selected
(component type and size).
If not, replace nozzle.
Tape splicing error
Cannot pickup
Problem Cause
Check/Solution Reference
Operating
procedure
3-2-6
6-1-13
9-1-6
Maintenance
6-5
1.Check whether proper splicing
has been done. Adjust if
necessary.
2.Check whether the same
components are properly joined.
Adjust if necessary.
Tape Splicing
Operating
Instructions
2
1.Make sure that there is no
clogging, wearing down, or
chipping of the nozzle tip.
Replace the nozzle if you find
anything wrong with it.
2.Check for a sliding error of the
nozzle holder. Modify if
necessary.
3.Check whether the nozzle is
magnetized or not .
Demagnetize it if magnetized.
Maintenance
4-1-1
Operating
procedure
6-2-4, 6-2-6,
6-2-8
What if
‐
‐
NPM-W2 EJM7DE-MB-01T-00
Misaligned
placement
Nozzle error
See 1-1-1-2
[Pickup error, Stand pickup]
Component data
error
What if
Troubleshooting
1-1-2
Placement error 1
1-1-2-1
Pickup condition
error
1-1-1-1 to 1-1-1-2
See [Cannot pickup]
Check whether the PCB support
pins are properly positioned.
Adjust if necessary.
(Check that the PCB support pin
does not interfere with the
component)
Check the PCB upper surface
warpage.
If it warps too much, do not use it.
Placement
condition error
Nozzle selection
error
Feeder error
PCB support
setting error
Poor PCB
Error in setting the
height of the placed
component
(interference with the
placed component)
Check whether the placed
component height is set up
properly.
Fix it if necessary.
Problem Cause
Check/Solution Reference
Operating
procedure
2-5-3
Operating
procedure
9-1-4
DGS
Programming
Manual
4
DGS
Programming
Manual
6
1.Check whether the placement
retainer is set up properly. Fix it
if necessary.
2.Check whether the vacuum
breaking pressure is set properly.
Adjust it as needed.
3.Check whether XY coordinates
of the production data is set up
properly. Adjust it if not correct.
4.Check for the placement timer
value.
Check whether component outline
and thickness, and dimensions of
each electrode are input correctly.
Adjust them if incorrect.
-
-
-
