NPM–W 2 EJM7DE-MB-02 -1T-00 Nzl Chg Mark Recog Err Nzl Changer C lose Err Nozz le Changer Op en Err Error Message Troubleshooting 2-1-3 Single stop er r or 13 Error Code Error Message Cause Inspection and Solution Nozzle…
NPM–W2 EJM7DE-MB-02-1T-00
Nozzle Recognition Err
Nozzle Pos Diameter Err
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Both nozzle position and
diameter were judged to be
abnormal during nozzle
position recognition.
(Single stop error occurred.)
Take any of the following measures:
1) Make sure that correct nozzles
are attached.
2)Check the nozzles are free of
bend or other defects.
40374
Nozzle recognition failed
during nozzle position
recognition.
(Single stop error occurred.)
Take any of the following measures:
1) Make sure that correct nozzles
are attached.
2) Check the nozzles are free of
bend or other defects.
3) Make sure the light of the parts
recognition camera is lit during
nozzle recognition. If not lit,
contact PFSC.
40375
2-1-3-23
NPM–W2 EJM7DE-MB-02-1T-00
Nzl Chg Mark Recog Err
Nzl Changer Close Err
Nozzle Changer Open Err
Error
Message
Troubleshooting
2-1-3
Single stop error 13
Error Code
Error Message
Cause Inspection and Solution
Nozzle changer failed to
open within the prescribed
time.
(Single stop error occurred.)
Choose [Machine] - [Adjust] - [All] -
[Output confirm] and open/close the
nozzle changer. Check for proper
movement. If stopped or caught on
the way, perform cleaning.
40376
Nozzle changer failed to
close within the prescribed
time.
(Single stop error occurred.)
Choose [Machine] - [Adjust] - [All] -
[Output confirm] and open/close the
nozzle changer. Check for proper
movement. If stopped or caught on
the way, perform cleaning.
40377
Failed to recognize the mark
of nozzle changer.
(Single stop error occurred.)
Make sure the mark of the nozzle
changer is free of dirt or dust.Make
sure the light of the head camera is
lit during recognition of nozzle
changer mark. If not lit, contact
PFSC.
40378
2-1-3-24
NPM–W2 EJM7DE-MB-02-1T-00
Nozzle Inst. Err
(Vacu)
Nozzle Remove Err
(Vacu)
Nozzle Missing Err
(Hd)
Unnecessary Nzl Err
(Hd)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
A nozzle was installed on a
head where it should not
have been.
(Single stop error occurred.)
Remove the applicable nozzle from
the head.
40379
No nozzle on a head where
the proper nozzle was
supposed to be installed.
(Single stop error occurred.)
Choose [Machine] - [Adjust] - [Head]
- [Nozzle exchange] and match the
mounting condition of the actual
nozzle and memory on the machine.
40380
Any of the following causes
is likely:
1) Nozzle failed to be
changed properly due to
dirt or dust on the nozzle^
nozzle holder or nozzle
changer.
2) Shutter is at fault.
(Single stop error occurred.)
Clean the nozzles, nozzle holders
and nozzle changer. If the error
persists, contact PFSC.
40381
Any of the following causes
is likely:
1) Nozzle failed to be
changed properly due to
dirt or dust on the nozzle^
nozzle holder or nozzle
changer.
2) Shutter is at fault.
(Single stop error occurred.)
Clean the nozzles, nozzle holders
and nozzle changer. If the error
persists, contact PFSC.
40382
2-1-3-25
