NPM–W 2 EJM7DE-MB-02 -1T-00 feederMemory Write Error Joint Detect Error Tape Jamming Error Error Message Troubleshooting 2-1-3 Single stop er r or 19 Error Code Error Message Cause Inspection and Solution The top tape ja…

NPM–W2 EJM7DE-MB-02-1T-00

Parts verification Error

PCB Bar Code Recog

Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Recognition mark is out of

camera's view.

2) Recognition error

occurred due to dirt on PCB.

3) PCB barcode recognition

coordinates are incorrect.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Using the inching function, move

the camera to the recognition mark

position and press the [Re-

recognize] button.

2) After cleaning the recognition

camera and PCB, press the [Re-

recognize] button. If the

recognition error occurs again,

move the camera to the

recognition mark position with the

[Pass] button or inching function

and press the [Manual set] button.

[Pass]: Pass the PCBs.[Manual

set]: Saves the inching amount as

the offset.

3) Choose [Production data] -

[Correct] - [PCB] - [PCB recog.]

and enter the correct PCB barcode

recognition coordinates.

40412

Component verification failed.

(Single stop error occurred.)

Verify the components again.If

something is wrong, replace with the

correct component.

40413

2-1-3-35

NPM–W2 EJM7DE-MB-02-1T-00

feederMemory Write Error

Joint Detect Error

Tape Jamming Error

Error

Message

Troubleshooting

2-1-3

Single stop error 19

Error Code

Error Message

Cause Inspection and Solution

The top tape jammed in the

mechanism or some other

trouble occurred.

(Single stop error occurred.)

1) Make sure the reel is properly

installed.

2) Make sure the tension sensor is

working properly.

40414

The tape joint was not

properly detected.

(Single stop error occurred.)

Take any of the following measures:

1) Make sure the reel is properly

installed.

2) Make sure the joint detection

sensor is working properly.

40415

Failed to write the

component information to the

feeder memory.

(Single stop error occurred.)

Check the feeder.

40416

2-1-3-36

NPM–W2 EJM7DE-MB-02-1T-00

Priming shot Tape feed

Priming shot Tape Exh.

Priming shot Recog Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Error occurred during

priming shot recognition.

(Single stop error occurred.)

Take any of the following measures:

1) Perform priming shot teaching

and check the condition of priming

shot.

2) Correct the parameter(s) that

caused the error.

40417

Tape of the priming shot unit

broke.

(Single stop error occurred.)

Take any of the following measures:

1) Change the tape.

2) Perform priming shot teaching

and check if the tape is properly

fed.

40418

Error occurred during feeding

tape of priming shot unit.

(Single stop error occurred.)

Perform priming shot teaching and

check if the tape is properly fed.If

the error persists, contact PFSC.

40419
