NPM–W 2 EJM7DE-MB-02 -1T-00 Nozzle barcod e recog error Syringe trans empty Trans auto-supp ly error Trans material empty Height Meas urement Error Error Message Troubleshooting 2-1-3 Single stop er r or 21 Error Code Er…

NPM–W2 EJM7DE-MB-02-1T-00

Loacl Height Result

Range Err

Mount point recog error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Recognition mark is out of

camera's view.

2) Recognition error

occurred due to dirt on

PCB^ etc.

3) Incorrect mounting point

recognition coordinates

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Using the inching function, move

the camera to the recognition mark

position and press the [Re-

recognize] button.

2) After cleaning the recognition

camera and PCB, press the [Re-

recognize] button. If the

recognition error occurs again,

press the [No Recognition] or

[Pass] button. [No Recognition]:

Move to the next action without

recognition. [Pass]: Pass the PCB.

3) Choose [Production data] -

[Correct] - [Mount] and enter the

correct mounting point recognition

coordinates.

40424

There are variations in height

measurement results.

(Single stop error occurred.)

Take any of the following measures:

1) Check the PCB.

2) Check the setting value of the

spot height result tolerance.

40425

2-1-3-39

NPM–W2 EJM7DE-MB-02-1T-00

Nozzle barcode recog

error

Syringe trans empty

Trans auto-supply error

Trans material empty

Height Measurement Error

Error

Message

Troubleshooting

2-1-3

Single stop error 21

Error Code

Error Message

Cause Inspection and Solution

Error occurred during

measurement of height

sensor.

(Single stop error occurred.)

Check the situation of the error

occurred and error message, and

contact PFSC.

40426

Material in the transcript table

is insufficient.

(Single stop error occurred.)

Supply the material to the stamper

table.

40427

Any of the following causes

is likely:

1) Tip of the syringe is

clogged.

2) Transcript material for the

syringe is insufficient.

3) Syringe not installed

properly.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Check the tip of the syringe.

2) Supply transcript material to the

syringe.

3) Make sure the syringe is installed.

40428

Transcript material in the

syringe is insufficient.

(Single stop error occurred.)

Supply transcript material to the

syringe.

40429

Nozzle in the changer to be

used for production does not

agree with the one saved in

the production data.

(Single stop error occurred.)

Check the barcode of the target

nozzle in the changer.

40430

2-1-3-40

NPM–W2 EJM7DE-MB-02-1T-00

No trans syringe

PCB Vacuum Error

Stop at S-tape sense

PCB warp set limit

abnormal

Can't PCB warp correction

PCB warp gradient

abnormal

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

PCB is warped too much.

(Single stop error occurred.)

Check the PCB.

40431

PCB is warped too much.

(Single stop error occurred.)

Check the PCB.

40432

PCB is warped too much.

(Single stop error occurred.)

Check the PCB.

40433

Splicing tape detected.

(Single stop error occurred.)

Check the splicing tape.

40434

Vacuum pressure for

vacuum-holding PCB

dropped. PCB may have not

been set properly.

(Single stop error occurred.)

Check the condition of the PCB.

After checking, set the PCB properly

and resume production.

40435

The syringe is not attached

correctly.

(Single stop error happened.)

Please check attachment of the

syringe.

40436

2-1-3-41
