NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Parts Recognition Error
Error
Message
Troubleshooting
2-1-3
Single stop error 26
Error Code
Error Message
Cause Inspection and Solution
Mismatch occurred in the
internal processing of
recognition function.Error
occurred in the parameter
area in the recognition
processing.
(Recognition error - Invalid
image processing
parameter )
Take any of the following measures:
1) Check the connection of
camera/sensor and lighting
units.Connected units can be
checked on the unit information
check screen.
2) Send the recognition data and
image detail data to PFSC.
43005
Mismatch occurred in the
internal processing of
recognition function.Error
occurred in the parameter
area in the recognition
processing.
(Recognition error - Invalid
image processing
parameter )
Take any of the following measures:
1) Check the connection of
camera/sensor and lighting
units.Connected units can be
checked on the unit information
check screen.
2) Send the recognition data and
image detail data to PFSC.
43006
2-1-3-50
NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Parts Recognition Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Error occurred in image
taking processing.
(Recognition error - Image
taking error (head camera))
Take any of the following measures:
1) Check the connection of
camera/sensor and lighting
units.Connected units can be
checked on the unit information
check screen.
2) Send the recognition data and
image detail data to PFSC.
43007
Error occurred in image
taking processing.
(Recognition error - Image
taking error (chip camera))
Take any of the following measures:
1) Check the connection of
camera/sensor and lighting
units.Connected units can be
checked on the unit information
check screen.
2) Send the recognition data and
image detail data to PFSC.
43008
2-1-3-51
NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Parts Recognition Error
Error
Message
Troubleshooting
2-1-3
Single stop error 27
Error Code
Error Message
Cause Inspection and Solution
Error occurred in the internal
parameter required for image
taking.
(Parameter-related error in
loading recognition error
image)
Take any of the following measures:
1) Check the connection of
camera/sensor and lighting
units.Connected units can be
checked on the unit information
check screen.
2) Send the recognition data and
image detail data to PFSC.
43009
Mismatch occurred in the
parameter used in the
internal processing of
recognition.
(Recognition error - Invalid
image processing
parameter )
Take any of the following measures:
1) Check the connection of
camera/sensor and lighting
units.Connected units can be
checked on the unit information
check screen.
2) Send the recognition data and
image detail data to PFSC.
43010
2-1-3-52
