NPM–W 2 EJM7DE-MB-02 -1T-00 Stamper return origin Error Stamper unit initial error The trans unit is not set up. Error Message Troubleshooting 2-1-3 Single stop er r or 20 Error Code Error Message Cause Inspection and So…
NPM–W2 EJM7DE-MB-02-1T-00
Priming shot Tape feed
Priming shot Tape Exh.
Priming shot Recog Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Error occurred during
priming shot recognition.
(Single stop error occurred.)
Take any of the following measures:
1) Perform priming shot teaching
and check the condition of priming
shot.
2) Correct the parameter(s) that
caused the error.
40417
Tape of the priming shot unit
broke.
(Single stop error occurred.)
Take any of the following measures:
1) Change the tape.
2) Perform priming shot teaching
and check if the tape is properly
fed.
40418
Error occurred during feeding
tape of priming shot unit.
(Single stop error occurred.)
Perform priming shot teaching and
check if the tape is properly fed.If
the error persists, contact PFSC.
40419
2-1-3-37
NPM–W2 EJM7DE-MB-02-1T-00
Stamper return origin
Error
Stamper unit initial error
The trans unit is not set up.
Error
Message
Troubleshooting
2-1-3
Single stop error 20
Error Code
Error Message
Cause Inspection and Solution
Transcript unit cannot be
confirmed.
(Single stop error occurred.)
Take any of the following measures:
1) Make sure the transcript unit is
set properly.
2) Remove and insert the transcript
unit.
40421
Failed to Initialize the
transcript unit properly.
(Single stop error occurred.)
Take any of the following measures:
1) Check the transcript unit.
2) Remove the transcript unit and
insert it again.
40422
Failed to return the transcript
unit to origin properly.
(Single stop error occurred.)
Take any of the following measures:
1) Check the transcript unit.
2) Remove the transcript unit and
insert it again.
40423
2-1-3-38
NPM–W2 EJM7DE-MB-02-1T-00
Loacl Height Result
Range Err
Mount point recog error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Recognition mark is out of
camera's view.
2) Recognition error
occurred due to dirt on
PCB^ etc.
3) Incorrect mounting point
recognition coordinates
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Using the inching function, move
the camera to the recognition mark
position and press the [Re-
recognize] button.
2) After cleaning the recognition
camera and PCB, press the [Re-
recognize] button. If the
recognition error occurs again,
press the [No Recognition] or
[Pass] button. [No Recognition]:
Move to the next action without
recognition. [Pass]: Pass the PCB.
3) Choose [Production data] -
[Correct] - [Mount] and enter the
correct mounting point recognition
coordinates.
40424
There are variations in height
measurement results.
(Single stop error occurred.)
Take any of the following measures:
1) Check the PCB.
2) Check the setting value of the
spot height result tolerance.
40425
2-1-3-39
