NPM–W2 EJM7DE-MB-02-1T-00
Cover Open
(Front Security Switch)
Servo Ready OFF
Emergency Stop Switch
ON
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 1
Error Code
Error Message
Cause Inspection and Solution
Emergency stop switch has
been pressed.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Turn the emergency stop switch
clockwise to reset.(One position
each at front and rear)
2) If the machine fails to be restored
even after pressing the emergency
stop switch, the switch may be
broken.Contact PFSC.
40001
Applicable axis is not ready.
(Self-diagnosis error
occurred.)
Please inquire from PFSC.
40002
Safety cover is open.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2)If the error persists even after the
safety cover is closed, the safety
switch may be broken.Contact
PFSC.
40003
2-1-2-1
NPM–W2 EJM7DE-MB-02-1T-00
Y Axis Interference
Conveyor Opening Sensor
Detect
Servo Switch Off
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Servo switch is OFF.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Turn the servo switch (One
position each at front and rear)
clockwise to turn it ON.
2) If the error persists even after the
servo switch is turned ON, the
switch may be broken.Contact
PFSC.
40004
Transfer opening sensor is
OFF.
(Self-diagnosis error
occurred.)
Check the condition of the adjoining
machines.Choose [Machine] -
[Adjust] - [All] - [Input confirm] and
check the condition of the transfer
opening sensor.
40005
Front X/Y axis and the Y-axis
of the rear X/Y axis interfered
with each other.
(Self-diagnosis error
occurred.)
If the error persists even after the
front and rear X/Y axes are
separated, contact PFSC.
40006
2-1-2-2
NPM–W2 EJM7DE-MB-02-1T-00
Tape Cover Detection1
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 2
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 1 is
blocked.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the top tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 1 of the
table is OFF when the light from
the emitter is blocked, and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked, and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
40007
