NPM–W2 EJM7DE-MB-02-1T-00
Camera IF board Device
driver error
IspBox SubSys Time out
error
IspBox SubSys Error
IspBox SubSys Production
data error
IspBox SubSys Production
data error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Invalid content was found in
the production data.
(Invalid production data.)
Create the production data again.
Then, download the production data
again.
1951
Failed to get the view data.
(Failed to get the view data.)
Check the applicable components
for inspection in the production data
and download the data again.
1952
Improper procedure was
taken in software processing.
(Inspection box system error
occurred.)
Restart the machine. If the error
persists, contact PFSC.
1953
Improper procedure was
taken in software processing.
(Timeout occurred in
software processing.)
Restart the machine. If the error
persists, contact PFSC.
1954
Improper procedure was
taken in software processing.
(Camera IF board driver
aborted.)
Restart the machine. If the error
persists, contact PFSC.
1955
2-1-4-88
NPM–W2 EJM7DE-MB-02-1T-00
Camera IF board Camera
parameter set error
Camera IF board Light
spot correction table set
error
Camera IF board Binary
table set error
Camera IF board Camera
capture parameter error
Camera IF board
Initialization error
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
45
Error Code
Error Message
Cause Inspection and Solution
Capture board could not be
initialized.
(Failed to initialize the
camera IF board.)
Check the connection of the camera
link cable between the inspection
head and inspection box.
1956
Improper procedure was
taken in software processing.
(Failed to obtain the capture
parameter.)
Restart the machine. If the error
persists, contact PFSC.
1957
Improper procedure was
taken in software processing.
(Failed to set the binary table
of the camera IF board.)
Restart the machine. If the error
persists, contact PFSC.
1958
Improper procedure was
taken in software processing.
(Failed to set the light spot
correction table of the
camera IF board.)
Restart the machine. If the error
persists, contact PFSC.
1959
Improper procedure was
taken in software processing.
(Failed to set the camera
parameters of the camera IF
board.)
Restart the machine. If the error
persists, contact PFSC.
1960
2-1-4-89
NPM–W2 EJM7DE-MB-02-1T-00
IspBox MainSys PCB skip
notification command
error
Camera IF board DMA
transfer error
Camera IF board
Exposure finish
information deal error
Camera IF board
Exposure finish
information start error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Improper procedure was
taken in software processing.
(Failed to set the exposure
completion notice of the
camera IF board.)
Restart the machine. If the error
persists, contact PFSC.
1961
Exposure finish information
could not be received.
(Failed to receive the
exposure completion notice
of the camera IF board.)
Check the connection of the camera
link cable.
1962
Image transfer from the
camera IF board to the
inspection box PC failed.
(Failed in DMA transfer of
image from the camera IF
board.)
Check the connection of the camera
link cable.
2001
Improper procedure was
taken in software processing.
(PCB skip information
command notified
incorrectly.)
Restart the machine. If the error
persists, contact PFSC.
2002
2-1-4-90
