4 Load Arrangement
drawings
NPM-W2 EJM7DE-MB-04T-00
4-1-1
Load arrangement
drawings 1
Troubleshooting
4-1
Front side
Feeder cart specification
Front side Rear side
Tray feeder specification (twin tray type)
Whole covers
■
■
Rear side
S301
G104
S302
S303
S304
G103
S301
S303
G104
S302
S304
G103
NPM-W2 EJM7DE-MB-04T-00
Front side Rear side
Tray feeder specification (single tray type)
Feeder table cover
Front side: B1200
Rear side: B1204
Front side: B1201T
Rear side: B1205T
Front side: B1202
Rear side: B1206
Front side: B1203T
Rear side: B1207T
Front side: S402
Rear side : S404
(This part does not exit for the rear side tray type.)
Front side: S401
Rear side : S403
(This part does not exit for the rear side tray type.)
Front side: B1200T
Rear side: B1204T
Front side: B1201
Rear side: B1205
Front side: B1202T
Rear side: B1206T
Front side: B1203
Rear side: B1207
Whole covers
■
Load arrangement
drawings
4-1-2
S301
S303
S304
G104
S302
G103
