NPM-W 2 EJM7DE-MB-04T-00 4-2-3 -6 Unit name No. Name Location Remark T win tray feeder main body B1622 Rep lenishment-section sh utter open ( B) B1623 Rep lenishment-section shu tter clos e (B) B1624 Presence or ab sence…
NPM-W2 EJM7DE-MB-04T-00
4-2-3-5
Unit name No. Name
Location Remark
Extension conveyor
(dual conveyor)
B1020
Transfer opening sensor (Left side)
B1021
Transfer opening sensor (Right side)
B1135
PCB detection lane 1 (Left side)
B1114
PCB detection lane 1 (Right side)
B1137
PCB detection lane 2 (Left side)
B1116
PCB detection lane 2 (Right side)
Single tray feeder
main body
B1322
Replenishment-section shutter open
B1323
Replenishment-section shutter close
B1324
Presence or absence of out-of-position pallet
(Light-receiving section)
B1324T
Presence or absence of out-of-position pallet
(Light-emitting section)
B1350
Magazine shutter Open Upper left
B1351
Magazine shutter Close Upper left
B1352
Magazine shutter Open Upper right
B1353
Magazine shutter Close Upper right
B1354
Magazine shutter Open Lower left
B1355
Magazine shutter Close Lower left
B1356
Magazine shutter Open Lower right
B1357
Magazine shutter Close Lower right
Single tray feeder lifter B1300
TL-axis +overrun
B1301
TL-axis -overrun
Single tray feeder
drawer
B1302
TP-axis +overrun
B1303
TP-axis -overrun
B1330
Pallet draw-out detection
B1331
Presence or absence of pallet at drawer axis
B1332
TP-axis drawing position
B1333
Presence or absence of pallet in TP slot
position (Light-receiving section)
B1333T
Presence or absence of pallet in TP slot
position (Light-emitting section)
Twin tray feeder main
body
B1322
Replenishment-section shutter open (A)
B1323
Replenishment-section shutter close (A)
B1324
Presence or absence of out-of-position pallet
(Light-receiving section) (A)
B1324T
Presence or absence of out-of-position pallet
(Light-emitting section) (A)
B1350
Magazine shutter Open Upper left (A)
B1351
Magazine shutter Close Upper left (A)
B1352
Magazine shutter Open Upper right (A)
B1353
Magazine shutter Close Upper right (A)
B1354
Magazine shutter Open Lower left (A)
B1355
Magazine shutter Close Lower left (A)
B1356
Magazine shutter Open Lower right (A)
B1357
Magazine shutter Close Lower right (A)
Load arrangement
drawings
NPM-W2 EJM7DE-MB-04T-00
4-2-3-6
Unit name No. Name
Location Remark
Twin tray feeder main
body
B1622 Replenishment-section shutter open (B)
B1623 Replenishment-section shutter close (B)
B1624
Presence or absence of out-of-position pallet
(Light-receiving section) (B)
B1624T
Presence or absence of out-of-position pallet
(Light-emitting section) (B)
B1650 Magazine shutter Open Upper left (B)
B1651 Magazine shutter Close Upper left (B)
B1652 Magazine shutter Open Upper right (B)
B1653 Magazine shutter Close Upper right (B)
B1654 Magazine shutter Open Lower left (B)
B1655 Magazine shutter Close Lower left (B)
B1656 Magazine shutter Open Lower right (B)
B1657 Magazine shutter Close Lower right (B)
Twin tray feeder lifter B1300 TL-axis +overrun (A)
B1301 TL-axis –overrun (A)
B1600 TL-axis +overrun (B)
B1601 TL-axis –overrun (B)
Twin tray feeder
drawer
B1302 TP-axis +overrun (A)
B1303 TP-axis –overrun (A)
B1330 Pallet draw-out detection
B1331 Presence or absence of pallet at drawer axis
B1332 TP-axis drawing position
B1333
Presence or absence of pallet in TP slot
position (Light-receiving section)
B1333T
Presence or absence of pallet in TP slot
position (Light-emitting section)
B1602 TP-axis +overrun (B)
B1603 TP-axis –overrun (B)
B1630 Pallet draw-out detection
B1631 Presence or absence of pallet at drawer axis
B1632 TP-axis drawing position
B1633
Presence or absence of pallet in TP slot
position (Light-receiving section)
B1633T
Presence or absence of pallet in TP slot
position (Light-emitting section)
Multifunctional transfer
unit
B001 Overflow detection sensor
Height sensor B1G00 Height sensor (Amplifier)
B1G00T Height sensor (Sensor head)
Load lists
Sensor list 4
Troubleshooting
4-2-3
Option
NPM-W2 EJM7DE-MB-04T-00
Unit name No. Name
Location Remark
Independent
changeover support
unit
B1542
Movable cover open check(Right side)
Front
B1542T
Movable cover open check(Left side)
Front
B1530T
Movable cover middle check(Left side)
Front
B1543
Movable cover open check(Right side)
Rear
B1543T
Movable cover open check(Left side)
Rear
B1531T
Movable cover middle check(Left side)
Rear
4-2-3-7
Load arrangement
drawings
