NPM–W2 EJM7DE-MB-02-1T-00
MMC CountUp Stop Error
Interference Parameter
Set Error
Servo Off Detection Error
Electronic Gear Operation
Overflow
Electronic Gear
Calculation Set Range
Overflow
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Improper procedure was
taken in software processing.
(Incorrect parameter setting
values.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1639
Improper procedure was
taken in software processing.
(Incorrect parameter setting
values.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1640
External servo signal may be
turned OFF.
(Servo free occurred during
motor movement.)
Eliminate the cause of servo free
and restart production. Then, check
the situation of the error occurred
and error message, and contact
PFSC.
1641
Improper procedure was
taken in software processing.
(Incorrect parameter setting
values.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1642
Trouble occurred in software
processing.
(Watchdog timer of the
machine software stopped.)
After turning OFF the machine
power, if the error persists, contact
PFSC.
1643
2-1-4-46
NPM–W2 EJM7DE-MB-02-1T-00
Hardware Detection
Motion Incomplete
Interfere Check Error
Continuous Operation
Setting Error
Software Limit Over Error
Servo Amplifier Detect
Error
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
24
Error Code
Error Message
Cause Inspection and Solution
Power to the machine may
be unstable.
(Instantaneous stop detected
in servo amplifier.)
After checking the power, if the error
persists, contact PFSC.
1644
Improper procedure was
taken in software processing.
(Incorrect parameter setting
values.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1645
Improper procedure was
taken in software processing.
(Incorrect parameter setting
values.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1646
Improper procedure was
taken in software processing.
(Interference may occur.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1647
The command issued by the
machine timed out. Head
motor has not finished the
operation.
(Head fails to move
properly.)
Turn the machine power back ON
and start production. Then, check
the situation of the error occurred
and error message, and contact
PFSC.
1649
2-1-4-47
NPM–W2 EJM7DE-MB-02-1T-00
Motion Incomplete
Origin Return
Uncompleted
Power On Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Origin return or movement
command was issued
without turning the power ON.
Emergency stop switch may
have been pressed or cover
may be opened.
(Head fails to move
properly.)
Turn the machine power back ON
and start production. Then, check
the situation of the error occurred
and error message, and contact
PFSC.
1650
Movement command was
issued before the axis
returned to origin.
(Head axis did not properly
return to origin. )
Close the error screen and perform
origin return. Then, restart
production. Check the situation of
the error occurred and error
message, and contact PFSC.
1651
Movement command was
issued before positioning
was completed.
(Head fails to move
properly.)
Close the error screen and perform
origin return. Then, restart
production. Check the situation of
the error occurred and error
message, and contact PFSC.
1652
2-1-4-48
