NPM–W 2 EJM7DE-MB-02 -1T-00 PrePickup Insp comm err (ISS) PrePickup Insp comm err (LNB) PrePickup Insp Error Error Message Troubleshooting 2-1-3 Single stop er r or 24 Error Code Error Message Cause Inspection and Soluti…

NPM–W2 EJM7DE-MB-02-1T-00

No recognition nozzle

error

Tape change action

incomplete

Pattern data error

Part Recog Err

(check drop)

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Error happened at the drop

detect before ejecting of the

parts recognition error or

pickup error.

(Recognition error Drop

detect before ejecting)

Please confirm that if there are parts

dropped on the PCB after finishing

the auto running and remove the

PCB.

40463

It is not possible to read the

recognition pattern data of

block match teach or

asymmetric array BGA

teach.Any of the following

causes is likely.

1) Device is not connected.

2) Recognition pattern data

is inexistent.

(Single stop error occurred.)

1) Please confirm the connect state

of LNB or SD card.

2) Please execute block match

teach or asymmetric array BGA

teach.

40464

Failed in tape change action.

(Single stop error occurred.)

Please set the new tape again from

the beginning.

40465

In nozzle confirm

processing^ it is detected

that the necessary nozzle for

recognition isn't arranged in

stocker.

(Single stop error occurred.)

Please set the nozzle to applicable

stocker.

40466

2-1-3-45

NPM–W2 EJM7DE-MB-02-1T-00

PrePickup Insp comm err

(ISS)

PrePickup Insp comm err

(LNB)

PrePickup Insp Error

Error

Message

Troubleshooting

2-1-3

Single stop error 24

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1)Parts direction is wrong.

2)Different parts is set.

3)The recognition data of

pre-pickup inspection is

wrong.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1)Please set correct direction.

2)Please set correct parts.

3)Please modify recognition data of

pre-pickup inspection

40467

The communication state is

abnormal between MC and

LNB.

(Single stop error occurred.)

Take any of the following measures:

1)Please confirm the

communication state between MC

and LNB.

2)Please confirm state or setting of

LNB.

40468

The communication state is

abnormal between LNB and

ISS(Inspection Server

Software).

(Single stop error occurred.)

Take any of the following measures:

1)Please confirm the

communication state between LNB

and ISS.

2)Please confirm state or setting of

ISS.

40469

2-1-3-46

NPM–W2 EJM7DE-MB-02-1T-00

non-collation

(verification2)

PartsTopSideRecCorrLim

Over

Nzl Height Last Val Diff

Err

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

The difference is over 0.1mm

compared to the last

measure result.

(Single stop error occurred.)

Check the mounting status of the

nozzle.Make sure that there is no

foreign body on the lens of the parts

recognition camera.Calibrate origin

offset Z-axis and multi recognition

camera offset.

40470

The offset position of

recognition object from parts

center is over the limit.

(Single stop error occurred.)

Please confirm if the following items

of head camera recognition

correction mount parameter are

set correctly in DGS.

1)The offset position of recognition

object from parts center

2)Limit

40471

Feeder which has been

pulled out and inserted^ but

has not executed verification

has been detected when

running starts.

(Single stop error occurred.)

Please start the production after

executing verification.

40472

2-1-3-47
