NPM–W 2 EJM7DE-MB-02 -1T-00 Magazine Shutter Ope n Error Supply Section Shutter Close Error Supply Section Shutter Open Erro r Origin Offset Acquire Error Solutions to errors Error Code Error Message Cause Inspection and…

NPM–W2 EJM7DE-MB-02-1T-00

Supply Position Pallet No.

Acquire Error

Pick-up Position Pallet No.

Acquire Error

Pallet Information Switch

Error

Defined Coordinate

Acquire Error

Error

Message

Troubleshooting

2-1-4

Emergency stop errors

Error Code

Error Message

Cause Inspection and Solution

Failed to obtain the

coordinates of TL/TP axes.

(Error obtaining defined

coordinates.)

Close the error screen and restart

production.If the error persists,

check the situation of the error

occurred and error message, and

contact PFSC.

2202

Failed to overwrite the pallet

information of pickup and

supply positions.

(Pallet information change

error occurred.)

Choose [Arrange] - [Parts prepare] -

[Tray] - [Check install] and check the

pallet Nos. set at the pickup and

supply positions of the tray and

correct them if necessary.

2203

Invalid pallet No. at the

pickup position.

(Pickup position pallet No.

acquisition error occurred.)

Choose [Arrange] - [Parts prepare] -

[Tray] - [Check install] and check the

pallet No. set at the pickup position

of the tray and correct them if

necessary.

2204

Invalid pallet No. at the

supply position.

(Supply position pallet No.

acquisition error occurred.)

Choose [Arrange] - [Parts prepare] -

[Tray] - [Check install] and check the

pallet Nos. set at the supply

position of the tray and correct them

if necessary.

2205

2-1-4-109

NPM–W2 EJM7DE-MB-02-1T-00

Magazine Shutter Open

Error

Supply Section Shutter

Close Error

Supply Section Shutter

Open Error

Origin Offset Acquire Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Failed to obtain origin offset

from the tray unit.

(Error obtaining origin offset.)

1) Check the connection with the

tray unit.

2) If the error persists, check the

situation of the error occurred and

error message, and contact PFSC.

2206

Supply shutter failed to close

or the limit switch failed to

detect the open shutter.

(Supply shutter open error

occurred.)

Choose [Machine] - [Adjust] - [All] -

[Input confirm] and check the

condition of the limit switch for

detecting the open/closed shutter.

2207

Supply shutter failed to open

or the limit switch failed to

detect the closed shutter.

(Supply shutter close error

occurred.)

Choose [Machine] - [Adjust] - [All] -

[Input confirm] and check the

condition of the limit switch for

detecting the open/closed shutter.

2208

Magazine shutter failed to

close or the limit switch failed

to detect the open shutter.

(Magazine shutter open error

occurred.)

Choose [Machine] - [Adjust] - [All] -

[Input confirm] and check the

condition of the limit switch for

detecting the open/closed shutter.

2209

2-1-4-110

NPM–W2 EJM7DE-MB-02-1T-00

TP Axis Stroke Sensor

Detection

Pallet Misalignment Error

Magazine Shutter Close

Error

Message

Troubleshooting

2-1-4

Emergency stop errors

Error Code

Error Message

Cause Inspection and Solution

Magazine shutter failed to

open or the limit switch failed

to detect the closed shutter.

(Magazine shutter close

error occurred.)

Choose [Machine] - [Adjust] - [All] -

[Input confirm] and check the

condition of the limit switch for

detecting the open/closed shutter.

2210

Pallet is partly out of the tray

magazine.

(Pallet misalignment error

occurred.)

Check the pallet position or the

sensor.

2211

TP-axis pullout position

sensor turned OFF.

(TP-axis stroke sensor

detection error occurred.)

Take any of the following measures:

1) Perform origin return again.

2) Choose [Machine] - [Adjust] - [All]

- [Input confirm] and make sure the

TP-axis pullout sensor is turned

ON.

2212
