NPM–W2 EJM7DE-MB-02-1T-00
Lack of necessary
Nozzles for Production
(Bad Nozzle)
No Proof stage
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Calibration plate stage not
installed.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Install the unit corresponding to
the head.
2) If the error persists even after the
unit is installed, the connection
with the unit may not be
detected.Choose [Machine] -
[Adjust] - [All] - [Input confirm] and
check the connection of units.
40020
Bad nozzles more than the
judgment value. Or required
nozzle is set as bad nozzle.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Choose [Machine] - [Set] - [Line
Camera/Multi Recognition
Camera] - [Action Parameter] and
check if the judgment value is
correct.
2) Choose [Machine] - [Set] - [Head]
- [Bad head] and identify the cause
(pickup error or recognition error).
Then perform appropriate
maintenance and clear the setting
of the bad nozzle.
40021
2-1-2-10
NPM–W2 EJM7DE-MB-02-1T-00
Production End Status
Detect
Bulk Changeover Cart
Insert Error
Feed section connect
error
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 6
Error Code
Error Message
Cause Inspection and Solution
Feeder cart connector not
connected.
(Self-diagnosis error
occurred.)
Connect the feeder cart
again.Choose [Machine] - [Adjust] -
[All] - [Input confirm] and check the
connection of feeder cart. If any
problem is found, contact PFSC.
40023
Cart insertion check switch
remains OFF.
(Self-diagnosis error
occurred.)
Check the condition of the cart
insertion check switch.If any
problem is found, contact PFSC.
40024
Production end status has
not been reset.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Choose [Arrange] - [Production
Plan] and clear the Carried in PCB
count if Production Plan Set is
[ON] and Carried in PCB count
has reached the planned
production count.
2) Reset the production end signal
of the front stocker. If the error
persists even after the signal is
cleared, the connection of the line
cable may be at fault.
3) Since the remote production
mode is engaged, operation
cannot be started manually.
40025
2-1-2-11
NPM–W2 EJM7DE-MB-02-1T-00
3D Sensor Connection
Supply A Cover Open
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Supply side door is open.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Close the supply side door if
opened.
2) If the error persists, the limit
switch may be broken.
3) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check the
condition of the supply side
door.ON : Door closedOFF: Door
open
40026
Error detected in the 3D
sensor connection check.
(Self-diagnosis error
occurred.)
1) Make sure the 3D sensor is
connected properly.
2) On the PnP List window, make
sure the 3D sensor is installed.
3) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check the
connection of the 3D sensor of the
detected table.
40028
2-1-2-12
