NPM–W 2 EJM7DE-MB-02 -1T-00 Nozz le Recognition Err or Nozzle Fall Error Message Troubleshooting 2-1-3 Sing le stop er r o r 6 Error Code Error Message Cause Inspection and Solution Any of the following causes is likely:…

NPM–W2 EJM7DE-MB-02-1T-00

Chip Eject Error

Part Drop

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Component dropped

during after recognition

before it was mounted.

2) Nozzle or filter clogged.

3) Component is not

securely picked up by the

nozzle.

4) Sensor may be at fault.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Remove dropped component and

restart the machine.

2) Clean the nozzle and filter.

3) Remove the component and

restart production.

4) Choose [Machine] - [Adjust] -

[Head] - [Vac output check] and if

any problem is found, contact

PFSC.

40327

Any of the following causes

is likely:

1) Recognition error

component failed to be

ejected to the eject box.

2) Nozzle or filter clogged.

3) Sensor may be at fault.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Remove the remaining

components from the nozzles and

restart the machine.

2) Clean the nozzle and filter.

3) Choose [Machine] - [Adjust] -

[Head] - [Vac output check] and if

any problem is found, contact

PFSC.

40328

2-1-3-9

NPM–W2 EJM7DE-MB-02-1T-00

Nozzle Recognition Error

Nozzle Fall

Error

Message

Troubleshooting

2-1-3

Single stop error 6

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Nozzle came off during

pickup or mounting.

2) Filter is clogged.

3) Sensor may be at fault.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Check the nozzle and attach it if it

came off.

2) Clean the filter.

3) Choose [Machine] - [Adjust] -

[Head] - [Vac output check] and if

any problem is found, contact

PFSC.

40329

Recognition error occurred

due to dirty mark^ etc.

(Single stop error occurred.)

Check if the time-lapse change

calibration mark is not dirty. Clean

the mark if dirty.

40330

2-1-3-10

NPM–W2 EJM7DE-MB-02-1T-00

Pickup Pos Recog Error

Nozzle Change Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Improper shutter action at

nozzle changer

2) Improper cylinder action

3) Deformed or bent nozzle

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Choose [Machine] - [Adjust] -

[Head] - [Nozzle exchange] and

open/close the nozzle changer.

Check for proper movement. If

stopped or caught on the way,

perform cleaning.

2) Replace the cylinder.

3) Replace the nozzle.

40331

Component is out of

camera's view.

(Single stop error occurred.)

Take measures in the following

order.

1) Move the camera to the center

position of the component using

the inching function and press the

[Recognize] button.

2) If the recognition error occurs

again, move the camera to the

center position of the component

using the inching function and

press the [Manual set]

button.[Manual set]: Save the

inching amount as the offset.

40332
