NPM–W 2 EJM7DE-MB-02 -1T-00 Parts Re cognition Error Solutions to errors Error Code Error Message Cause Inspection and Solution Detected co mponent center position is incorrect. - C omponent de tection position is beyond…
NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Error
Message
Troubleshooting
2-1-3
Single stop error 32
Error Code
Error Message
Cause Inspection and Solution
Detected component result
angle is abnormal.
- Component detection angle
has exceeded the prescribed
range (±30ﾟ).This error
occurs also when improper
judgment was determined
after Recognition option: Tilt
range check was added.
(Recognition error - Invalid
component recognition
angle)
Take any of the following measures:
1) Check the component pickup
position and pickup condition.
Make sure the component pickup
position is not placed at the center
and the component is not likely to
be in the slanted pickup posture.
2) When the recognition option for
checking the recognition result
angle is specified, check the
allowable range.
3) Check the component package
angle for asymmetric component
shape such as 5-pin Tr.
43021
2-1-3-62
NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Detected component center
position is incorrect.
- Component detection
position is beyond the
specified area range.
- With 1-way lead array
component^ component
center position calculated
from lead column is out of
recognition screen.This
error occurs also when
improper judgment was
determined after the
following recognition
options were added.
Ans22(51): Center area
check Ans22(52):
Protrusion check
Ans22(53): Adjoining mount
check
(Recognition error -
Component recognition
position)
Take any of the following measures:
1) Check the component pickup
position and pickup
condition.Make sure the
component pickup position is not
placed at the center and the
component is not likely to be in the
slanted pickup posture.
2) When the recognition option for
checking the recognition result
position is specified, check the
allowable range.
43022
2-1-3-63
NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Error
Message
Troubleshooting
2-1-3
Single stop error 33
Error Code
Error Message
Cause Inspection and Solution
Detected component size in
L (X) direction is
invalid.Component size in L
direction differs widely from
registered data.
(Recognition error -
Measurement result in size L
direction)
Take any of the following measures:
1) Check the component outer
shape size and the distance of
shapes in L (X) direction.For
components with electrodes at
both sides, check the distance
between the electrodes.In case of
a recognition error of Ans25
(30~39), an error is detected when
performing detailed check of the
component size.If the component
size varies widely and variation
can be tolerated with actual
components, specify the
Recognition option: Component
size limit.
2) Check the image status of the
component at both sides.If the
shape of the ends like J-lead
component or curved component
is unclear on the image, adjust the
lamp value and correct the image
status.(At this time, the side
lighting is effective.)
3) Check the component pickup
position and pickup
condition.Make sure the
component pickup position is not
placed at the center and the
component is not likely to be in the
slanted pickup posture.
43025
