NPM-W 2 EJM7DE-MB-04T-00 Load lists R e gula tor list Troubleshooting 4-2-5 Option Unit name No. Name Location Remark 3-nozzle head B5001 Mount load control Dispensing head B5001 Electro pneumat ic regulator 4-2-5 Load a…
NPM-W2 EJM7DE-MB-04T-00
Load lists
Switch list
Troubleshooting
4-2-4
Standard unit
Option
Unit name No. Name
Location Remark
Main body S301
Safety cover
Front
S302
Safety cover
Rear
S303
Safety cover
Front Hinge type
S304
Safety cover
Rear Hinge type
S3211
Truck installation check
Front
S3217
Truck installation check
Rear
Feeder table cover
(front)
S401 Feeder safety cover 1 Front
S402 Feeder safety cover 2 Front
Feeder table cover
(rear)
(feeder type)
S403 Feeder safety cover 3 Rear
S404 Feeder safety cover 4 Rear
Unit name No. Name
Location Remark
Single tray feeder
main body
S0325
Replenishment-completion switch
S0327
Replenishment door switch
S3334
Magazine change door key switch
Twin tray feeder S0325
Replenishment-completion switch (A)
S0327
Replenishment door switch (A)
S3334 Magazine change door key switch (A)
S0625
Replenishment-completion switch (B)
S0627
Replenishment door switch (B)
S3634 Magazine change door key switch (B)
Multifunctional
transfer unit
S301 Safety cover
Independent
changeover support
unit
S3532 Movable cover close (Right side) Front
S3532T Movable cover close (Left side) Front
S3537 Movable cover close (Right side) Rear
S3537T Movable cover close (Left side) Rear
4-2-4
NPM-W2 EJM7DE-MB-04T-00
Load lists
Regulator list
Troubleshooting
4-2-5
Option
Unit name No. Name
Location Remark
3-nozzle head B5001 Mount load control
Dispensing head B5001
Electro pneumatic regulator
4-2-5
Load arrangement
drawings
NPM-W2 EJM7DE-MB-04T-00
4-2-6
Load lists
Heater list
Troubleshooting
4-2-6
Option
Unit name No. Name
Location Remark
Dispensing head E2002 Heater 1
E2003 Heater 2
