NPM–W 2 EJM7DE-MB-02 -1T-00 Conveyor opening Sensor Detect (Right) Conveyor opening Sensor Detect (Left) Emergency Stop Switch ON Solutions to errors Error Code Error Message Cause Inspection and Solution Emergency stop …
NPM–W2 EJM7DE-MB-02-1T-00
Momentary Power OFF
Cover Open
(Rear Side Safety switch
interior side)
Cover Open
(Front Side Safety switch
interior side)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
2
Error Code
Error Message
Cause Inspection and Solution
Safety cover is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
1306
Safety cover is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
1307
Power supply may have
been stopped momentarily
due to power failure.
(Interlock occurred.)
Check the voltage of the power
supply in the plant. Turn the
machine power back ON and start
production. If the error persists,
contact PFSC.
1308
2-1-4-3
NPM–W2 EJM7DE-MB-02-1T-00
Conveyor opening Sensor
Detect
(Right)
Conveyor opening Sensor
Detect
(Left)
Emergency Stop Switch
ON
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Emergency stop switch has
been pressed.
(Interlock occurred.)
Take measures in the following
order.
1) Turn the emergency stop switch
clockwise to reset.(One position
each at front and rear)
2) If the machine fails to be restored
even after resetting the emergency
stop switch, the switch may be
broken.Contact PFSC.
1309
Transfer opening sensor
(Left) is OFF.
(Interlock occurred.)
Check the condition of the adjoining
machine on the left.Choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check the condition of
the transfer opening sensor (Left).
1310
Transfer opening sensor
(Right) is OFF.
(Interlock occurred.)
Check the condition of the adjoining
machine on the right.Choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check the condition of
the transfer opening sensor (Right).
1311
2-1-4-4
NPM–W2 EJM7DE-MB-02-1T-00
Feeder Pull-out Detect
(Rear)
Feeder Pull-out Detect
(Front)
Air Pressure Error
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
3
Error Code
Error Message
Cause Inspection and Solution
Abnormal air pressure
(Interlock occurred.)
Take any of the following measures:
1)Please adjust the regulator when
the supplied air pressure is low.
Please refer to the operating
instruction(Maintenance
articles)about setting pressure.
2)If the air pressure detection
setting(Low limit setting) is too
high, error occurs. Please set the
air pressure detection value to
0.4MPa.
1312
Feeder was pulled out due to
a reason other than
component exhaust.
(Interlock occurred.)
Set the feeder again.
1313
Feeder was pulled out due to
a reason other than
component exhaust.
(Interlock occurred.)
Set the feeder again.
1314
2-1-4-5
