NPM–W 2 EJM7DE-MB-02 -1T-00 Conveyor Width Adj. Err PCB Transfer Error PCB Recognition Error Solutions to errors Error Code Error Message Cause Inspection and Solution Any of the following causes is likely: 1) R ecogniti…
NPM–W2 EJM7DE-MB-02-1T-00
Feeder Error Rate Over
Bad Nozzle Rate Over
Error
Message
Troubleshooting
2-1-3
Single stop error 3
Error Code
Error Message
Cause Inspection and Solution
No. of bad nozzles has
exceeded the preset count.
(Single stop error occurred.)
Take any of the following measures:
1) Choose [Machine] - [Set] - [Head]
- [Action Parameter] and make
sure the judgment value is correct.
2) Choose [Machine] - [Set] - [Head]
- [Bad head] and identify the cause
(pickup error or recognition error).
Then perform appropriate
maintenance and reset the setting
of bad nozzles.
40311
Pickup error rate for the
feeder has exceeded the
setting value.
(Single stop error occurred.)
Take any of the following measures:
1) Make sure the tape is not
jammed.
2) Make sure the parameters of the
component data are set properly.
40312
2-1-3-4
NPM–W2 EJM7DE-MB-02-1T-00
Conveyor Width Adj. Err
PCB Transfer Error
PCB Recognition Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Recognition mark is out of
camera's view.
2) Recognition error
occurred due to dirt on PCB.
3) PCB recognition
coordinates are incorrect.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Using the inching function, move
the camera to the recognition mark
position and press the Re-
recognize button.
2) After cleaning the recognition
camera and PCB, press the Re-
recognize button. If the recognition
error occurs again, move the
camera to the recognition mark
position with the Pass button or
inching function and press the
Manual set button. [Pass]: Pass
the PCB.[Manual set]: Save the
inching amount as the offset.
3) Choose [Production data] -
[Correct] - [PCB] - [PCB recog.]
and enter the correct PCB
recognition coordinates.
40313
PCB failed to be transferred
properly.
(Single stop error occurred.)
Check inside the machine and
remove the PCB.
40314
Width adjustment is disabled
because of the PCB on the
conveyor.
(Single stop error occurred.)
Remove the PCB.
40315
2-1-3-5
NPM–W2 EJM7DE-MB-02-1T-00
Splicing Length Stop
Cover Open
PCB Position Error
Error
Message
Troubleshooting
2-1-3
Single stop error 4
Error Code
Error Message
Cause Inspection and Solution
PCB is removed or is not
placed at the correct position.
(Single stop error occurred.)
1) Set the PCB in position.
2) If the PCB is removed, press the
[PCB Remove] button.
40316
Safety cover is open.
(Single stop error occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
40317
Tape is getting low.
(Single stop error occurred.)
Perform tape splicing.
40318
2-1-3-6
