NPM–W 2 EJM7DE-MB-02 -1T-00 PCB Warp Range Over PCB Warp Measurement Error Part Thic kness Measur e Error Nozzle Height Measure Error PCB Thick ness Measure Error Error Message Troubleshooting 2-1-3 Sing le stop er r o r…

NPM–W2 EJM7DE-MB-02-1T-00

Pick-up Height Measure

Error

No Splicing Check Warn.

No Splicing Check

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Splicing work not

performed.

2) Spliced part of the tape

has been recognized by

mistake.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Perform splicing work properly.

Make sure the reel is properly

installed and check the joint

detection sensor. Then, press the

Supply Complete button.

2) Cancel the joint detection.

40319

Any of the following causes

is likely:

1) Splicing work not

performed.

2) Spliced part of the tape

has been recognized by

mistake.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Perform splicing work properly.

Make sure the reel is properly

installed and check the joint

detection sensor. Then, press the

Supply Complete button.

2) Cancel the joint detection.

40320

Feeder or tray not set from

which the component is

picked up.

(Single stop error occurred.)

Make sure that the feeder or pallet is

properly set and the nozzle is

properly set on the head.

40321

2-1-3-7

NPM–W2 EJM7DE-MB-02-1T-00

PCB Warp Range Over

PCB Warp Measurement

Error

Part Thickness Measure

Error

Nozzle Height Measure

Error

PCB Thickness Measure

Error

Message

Troubleshooting

2-1-3

Single stop error 5

Error Code

Error Message

Cause Inspection and Solution

Feeder or tray not set from

which the component is

picked up.

(Single stop error occurred.)

Make sure that the feeder or pallet is

properly set and the nozzle is

properly set on the head.

40322

Nozzle may be wrong.

(Single stop error occurred.)

Check the nozzle.

40323

Component height data may

be incorrect.

(Single stop error occurred.)

Check the component.

40324

PCB is warped too much.

(Single stop error occurred.)

Check the PCB.

40325

PCB is warped too much.

(Single stop error occurred.)

Check the PCB.

40326

2-1-3-8

NPM–W2 EJM7DE-MB-02-1T-00

Chip Eject Error

Part Drop

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Component dropped

during after recognition

before it was mounted.

2) Nozzle or filter clogged.

3) Component is not

securely picked up by the

nozzle.

4) Sensor may be at fault.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Remove dropped component and

restart the machine.

2) Clean the nozzle and filter.

3) Remove the component and

restart production.

4) Choose [Machine] - [Adjust] -

[Head] - [Vac output check] and if

any problem is found, contact

PFSC.

40327

Any of the following causes

is likely:

1) Recognition error

component failed to be

ejected to the eject box.

2) Nozzle or filter clogged.

3) Sensor may be at fault.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Remove the remaining

components from the nozzles and

restart the machine.

2) Clean the nozzle and filter.

3) Choose [Machine] - [Adjust] -

[Head] - [Vac output check] and if

any problem is found, contact

PFSC.

40328

2-1-3-9
