NPM–W2 EJM7DE-MB-02-1T-00
Motion Incomplete
Origin Return
Uncompleted
Power On Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Origin return or movement
command was issued
without turning the power ON.
Emergency stop switch may
have been pressed or cover
may be opened.
(Head fails to move
properly.)
Turn the machine power back ON
and start production. Then, check
the situation of the error occurred
and error message, and contact
PFSC.
1650
Movement command was
issued before the axis
returned to origin.
(Head axis did not properly
return to origin. )
Close the error screen and perform
origin return. Then, restart
production. Check the situation of
the error occurred and error
message, and contact PFSC.
1651
Movement command was
issued before positioning
was completed.
(Head fails to move
properly.)
Close the error screen and perform
origin return. Then, restart
production. Check the situation of
the error occurred and error
message, and contact PFSC.
1652
2-1-4-48
NPM–W2 EJM7DE-MB-02-1T-00
Parameter Error
Command Error
Emergency Stop
(Controller)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
25
Error Code
Error Message
Cause Inspection and Solution
Emergency stop signal was
input to the head unit.
(Head axis stopped.)
1) Turn the emergency stop switch
clockwise to reset.(One position
each at front and rear)
2) If the machine fails to be restored
even after pressing the emergency
stop switch, the switch may be
broken.Contact PFSC.
1656
Improper procedure was
taken in software processing.
(Unsupported command in
the head command issued.)
Close the error screen and perform
origin return. Then, restart
production. Check the situation of
the error occurred and error
message, and contact PFSC.
1658
Improper procedure was
taken in software processing.
e.g.: 2 has been set although
available parameter is 0 or 1.
(Invalid parameter setting.)
Close the error screen and perform
origin return. Then, restart
production. Check the situation of
the error occurred and error
message, and contact PFSC.
1660
2-1-4-49
NPM–W2 EJM7DE-MB-02-1T-00
Overload Anomaly
Origin Return Abnormality
Commutation Anomaly
Communication Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Check sum error occurred in
the communication data from
the host to the head.
(Communication error
occurred.)
Clean the drawer connectors for
connecting head, and check the
wiring connected to them. If the
error persists, contact PFSC.
1661
Communication with the
encoder failed to finish
properly during origin return
immediately after power ON.
(Magnetic pole detection
error occurred.)
Check the connection between the
head motor and control board inside
the head and restart production.
Then, check the situation of the
error occurred and error message,
and contact PFSC.
1662
Origin return failed to finish
within the prescribed time
and timeout occurred.
(Head axis did not properly
return to origin. )
Check the situation of the error
occurred and error message, and
contact PFSC.
1664
Positional deviation with
power ON or integrated
current is beyond the
specified value.
(Head movement stopped
due to overload.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1665
2-1-4-50
