NPM–W 2 EJM7DE-MB-02 -1T-00 Servo amplifier communication busy error RFID communication busy error FRAM proces sing Error Servo amplifier communication error RFID communication error Error Message Troubleshooting 2-1-4 E…

100%1 / 338
NPM–W2 EJM7DE-MB-02-1T-00
Machine parameter check
sum error
IspBox Unconnected Err
(Ready signal undetected
when starting)
Inspector Box
communication error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Inspection box has not
been connected.
2) Power was turned OFF
without shutting down the
machine on the last
occasion.
(Communication with the
inspection box cannot be
confirmed.)
Take measures shown with the
same number as that of the cause.
1) Check the connection of the
inspection box.
2) Turn OFF power once and turn it
back ON in one minute.
2111
Ready signal of the
inspection box failed to be
detected.
(Start-up of inspection box
not detected.)
Take any of the following measures:
1) Check the connection of the
inspection box.
2) Turn OFF power once and turn it
back ON in one minute.
3) If the error persists, contact
PFSC. It is possible to product
without inspection if set to ON the
bad beam of the inspect head.
2112
Improper procedure was
taken in software processing.
(Check sum error occurred in
the machine parameter.)
Return to the main menu and restart
production. If the error persists,
contact PFSC.
2115
2-1-4-94
NPM–W2 EJM7DE-MB-02-1T-00
Servo amplifier
communication busy error
RFID communication busy
error
FRAM processing Error
Servo amplifier
communication error
RFID communication error
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
48
Error Code
Error Message
Cause Inspection and Solution
No response from the RFID
unit.
(RFID communication error
occurred.)
Check the wiring connected to the
RFID unit. If the error persists,
contact PFSC.
2116
Improper procedure was
taken in software processing.
(Error occurred in
communication with the
servo amplifier.)
Check the wiring connected to the
servo amplifier. If the error persists,
contact PFSC.
2117
Improper procedure was
taken in software processing.
(Error occurred in the FRAM
processing.)
Return to the main menu and restart
production. If the error persists,
contact PFSC.
2120
Improper procedure was
taken in software processing.
(Another communication
attempted during
communication with RFID.)
Return to the main menu and restart
production. If the error persists,
contact PFSC.
2121
Improper procedure was
taken in software processing.
(Another communication
attempted during
communication with servo
amplifier.)
Return to the main menu and restart
production. If the error persists,
contact PFSC.
2122
2-1-4-95
NPM–W2 EJM7DE-MB-02-1T-00
Transfer Command
Received when Power is
Off
Transfer Command
Received in Power-off
Process
Transfer Command
Received in Axis Moving.
Command Received in
Interlock Status
FRAM communication
busy error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Improper procedure was
taken in software processing.
(Another FRAM processing
was attempted during FRAM
processing.)
Return to the main menu and restart
production. If the error persists,
contact PFSC.
2123
Improper procedure was
taken in software processing.
(Movement command issued
when interlock was
engaged.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
2125
Improper procedure was
taken in software processing.
(Movement command issued
while the axis was moving.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
2126
Improper procedure was
taken in software processing.
(Movement command issued
in the power ON processing.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
2127
Improper procedure was
taken in software processing.
(Movement command issued
when power was OFF.)
Check the condition of the
emergency stop switch and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
2128
2-1-4-96
