NPM–W 2 EJM7DE-MB-02 -1T-00 Parts Re cognition Error Error Message Troubleshooting 2-1-3 Single stop er r or 37 Error Code Error Message Cause Inspection and Solution Detected ele ctrode cou nt does not agree with regis …

NPM–W2 EJM7DE-MB-02-1T-00

Parts Recognition Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Lead length of lead array

components is not uniform

for lead column.Lead is

protruded partly for lead

arrangement.Bent

(straightened) lead

(Recognition error -

Electrode length)

Take any of the following measures:

1) Check the arrangement condition

of the component's electrodes.If

the lead length differs partly,

component concerned correctly.

2) Check the component pickup

position and pickup

condition.Make sure the

component pickup position is not

placed at the center and the

component is not likely to be in the

slanted pickup posture.

43034

Pitch between adjoining

electrodes for evenly spaced

array electrode components

is improper^ or entire length

of electrode arrangement is

invalid.This error also occurs

with unevenly spaced BGA

components^ if the detected

ball position deviates greatly

from the teaching position.

(Recognition error -

Electrode pitch)

Take any of the following measures:

1) Check the component for bent

lead.

2) Check the pitch data to be

registered.If the amount of bent

can be tolerated with the

component with actually bent lead,

specify the allowable lead bent

(pitch) of the recognition option.In

case of the error of Ans35 (35), the

entire length of electrode

arrangement is judged to be

invalid.In such a case, check the

pitch data to be registered.

43035

2-1-3-71

NPM–W2 EJM7DE-MB-02-1T-00

Parts Recognition Error

Error

Message

Troubleshooting

2-1-3

Single stop error 37

Error Code

Error Message

Cause Inspection and Solution

Detected electrode count

does not agree with

registered count.Required

electrode count not

detected.Electrode in similar

shape detected around

registered electrode.

(Recognition error -

Electrode count)

Take any of the following measures:

1) Check the condition of the

component's electrodes.In case of

the error of Ans36 (30-39), an

error is detected when performing

detailed check. At this time, check

if the registered count of electrode

is correct.

2) Check the image status

(brightness) of component's

electrodes.In case of the error of

Ans36 (20-29), an error is detected

in the general positioning

processing of electrode

arrangement.At this time, check for

proper electrode size (width,

diameter), or check for proper

electrode image.If the electrodes

are unclear on the image, adjust

the lamp value.

43036

2-1-3-72

NPM–W2 EJM7DE-MB-02-1T-00

Parts Recognition Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

The electrode array of an

electrode (lead or ball type)

array component was not

properly detected because

either the electrode pitch or

quantity was determined to

be incorrect.The detected

electrode pitch does not

match input data.The input

quantity of electrodes were

not detected.

(Recognition error -

Electrode pitch or count)

Check the registered electrode

arrangement data (lead group, ball

group).Make sure the registered

shape data agrees with the actual

component image.Make sure the

registered arrays and pitches agree

with the actual component status.

43037
