NPM–W 2 EJM7DE-MB-02 -1T-00 Auto Product Change Err Abnormal Picku p Height Pickup He ight Measure Err Error Message Troubleshooting 2-1-3 Single stop er r or 10 Error Code Error Message Cause Inspection and Solution The…

NPM–W2 EJM7DE-MB-02-1T-00

Inspect Machine FB

Warning

Opening Sensor Det.

(L)

Opening Sensor Det.

(R)

Lead/Ball Float Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Component lead (or ball)

float detected by the 3D

sensor or multi recognition

camera.

(Single stop error occurred.)

Take any of the following measures:

1) Make sure the parameters of the

component data are set properly.

2) Check the components for any

problem.

40351

Obstacle detected at the

right NPM conveyor outer

opening sensor or left

opening sensor of the

adjoining machine.

(Single stop error occurred.)

Remove the obstacle from the right

NPM conveyor outer opening

sensor or left opening sensor of the

adjoining machine.

40352

Obstacle detected at the left

NPM conveyor outer opening

sensor or right opening

sensor of the adjoining

machine.

(Single stop error occurred.)

Remove the obstacle from the left

NPM conveyor outer opening

sensor or right opening sensor of

the adjoining machine.

40353

Same kind of error occurred

three times continuously at

each mounting point.

(Single stop error occurred.)

Check the error message and press

the Return button.

40354

2-1-3-17

NPM–W2 EJM7DE-MB-02-1T-00

Auto Product Change Err

Abnormal Pickup Height

Pickup Height Measure

Err

Error

Message

Troubleshooting

2-1-3

Single stop error 10

Error Code

Error Message

Cause Inspection and Solution

The head lowered to the soft

limit before detected by the

cushion end sensor^

because either the feeder or

tray was improperly set.

(Single stop error occurred.)

Make sure the feeder or pallet is set

properly. Make sure the nozzle is

attached to the head properly.

40355

Any of the following causes

is likely:

1) There is obstacle at the

pickup part.

2) Feeder not set.

3) Nozzle not attached.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Remove the obstacle from the

pickup part.

2) Set the feeder.

3) Attach the nozzle.

40356

Any of the following causes

is likely:

1) Failed to switch the

production data.

2) Failed to notify the

production changeover

information to the next

process machine.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Make sure the production data

can be loaded from the LNB.

2) Check the communication and

setting conditions of the next

process machine.

40357

2-1-3-18

NPM–W2 EJM7DE-MB-02-1T-00

Inspect Mc Feedback Err

Pick-up Pos Gap Detect

Parts verify Request Stop

Filter Clearing

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Nozzle filter clogged.

2) Nozzle clogged.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Clean the nozzle filter.

2)Clean the nozzle.

40358

Stop information arrived from

the component verification

system.

(Single stop error occurred.)

Production can be restarted if the

request to stop command is reset.

40359

Feeder's pickup position is

displaced by the unit of pitch.

(Single stop error occurred.)

Adjust the pickup position with the

[Feed] button.

40360

Same kind of error occurred

10 times in one hour at each

mounting point.

(Single stop error occurred.)

Press the [Solution] button.

40361

2-1-3-19
