NPM–W2 EJM7DE-MB-02-1T-00
Down Lead Check Error
Fly Pattern Check Error
Error
Message
Troubleshooting
2-1-3
Single stop error 43
Error Code
Error Message
Cause Inspection and Solution
Skipped pattern detected in
skipped pattern check.
(Inspection error occurred
during priming shot
recognition. )
Take any of the following measures:
1) Perform priming shot teaching
and check the shot condition.
2) Correct the parameter(s) that
caused the error. Lower the setting
temperature of adhesive to reduce
adhesive scattering.
43505
Cobwebbing detected in
cobwebbing check.
(Inspection error occurred
during priming shot
recognition. )
Take any of the following measures:
1) Perform priming shot teaching
and check the shot condition.
2) Correct the parameter(s) that
caused the error. Increase the
setting value at the head rising
position to heighten the pull-up
height of the nozzle. Raise the
setting temperature of adhesive to
reduce cobwebbing.
43506
2-1-3-84
NPM–W2 EJM7DE-MB-02-1T-00
Recog Param Error
(Pixel Rate)
Area Rate Check Error
Total Area Check Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Total dot area size are
detected abnormal.
(Inspection error occurred
during priming shot
recognition. )
Take any of the following measures:
1) Perform priming shot teaching
and check the shot condition. The
reference value of the area can be
taught.
2) Correct the parameter(s) that
caused the error. Adjust the
dispensing time and reference
area value.
43507
Proportion between large dot
size and small dot size is
abnormal in the area check.
(Inspection error occurred
during priming shot
recognition. )
Take any of the following measures:
1) Clean the nozzle in use.
2) Perform priming shot teaching
and check the shot condition.
3) Correct the parameter(s) that
caused the error.
43508
Abnormal pixel rate of head
camera.
(Recognition parameter error
(pixel rate) occurred.)
Check the pixel rate of the head
camera. If the error persists, contact
PFSC.
43509
2-1-3-85
NPM–W2 EJM7DE-MB-02-1T-00
Rcg Prm Err
(DownLead JudgeV)
Recog Param Error
(NZL Size D)
Recog Param Error
(NZL Size W)
Recog Param Error
(NZL Size L)
Recog Param Error
(Angle)
Error
Message
Troubleshooting
2-1-3
Single stop error 44
Error Code
Error Message
Cause Inspection and Solution
Abnormal recognition angle.
(Recognition parameter error
(recognition angle) occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
43510
Invalid nozzle shape space.
(Recognition parameter error
(nozzle size L) occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
43511
Invalid nozzle shape space.
(Recognition parameter error
(nozzle size W) occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
43512
Invalid nozzle space
diameter.
(Recognition parameter error
(nozzle size D) occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
43513
Invalid judgment value of
cobwebbing in priming shot
recognition data.
(Recognition parameter error
(threading judgment value)
occurred.)
Check the judgment value of
threading. If the error persists,
contact PFSC.
43514
2-1-3-86
