AHB01EDTP Section 3 Component Library 0308-002 3 - A This section describes the outline of the component library and how to navigate in each window . Refer to another instruction manual "COMPONENT LIBRARY (TIM-X Ser…
Fig. 3B178 "O-data" Tab Sheet
• Operation Procedure
New Creation of "O-data" Tab
(1) When the second toolbar is not visible, press the [Second Toolbar]
icon ( ). The second toolbar opens.
(2) Touch or select the "Un" tab where a "P-data" tab should be added
with the pointing device.
(3) Select the [Add Repetitive O Data] icon (
). a new "O-data" tab
is added.
Deletion of "O-data" Tab
(1) When the second toolbar is not visible, press the [Second Toolbar]
icon (
). The second toolbar opens.
(2) Touch or select the "Un" tab that contains the offset data (repeti-
tive O data) to be deleted with the pointing device.
(3) Select the [Delete Repetitive O Data] icon (
). The "O-data"
tab of the selected U data is deleted.
0206-001 2-113
AHB01EDTP
4.4 "Placement Data" Tab
AHB01EDTP
Section 3
Component Library
0308-002 3-A
This section describes the outline of the component library
and how to navigate in each window.
Refer to another instruction manual "COMPONENT
LIBRARY (TIM-X Series)" for the description and creation
of component library data.
AHB01EDTP
0107-001 3-B
