0206-002 5-103 AHB01EDTP

4.2 "Password" Tab

The corresponding tab sheet enables the operator to set a password

and the scope of authority according to the given authority.

The "Password" tab sheet is provided with the following 3 tab sheets.

When a tab is pressed, the corresponding tab sheet appears.

Table 3E15

Tabs Description

Password Set The corresponding tab sheet enables the operator to set a password

according to the given authority.

Available Area Set (1/2) The corresponding tab sheet enables the operator to specify the scope

of authority to use the described functions ("Operation Mode (Modify)"

through "Placement Head/Noz Data").

Available Area Set (2/2) The corresponding tab sheet enables the operator to specify the scope

of authority to use the described functions ("Unit Adjustment" through

"Machine Set-up").

4.2.1 "Password Set" Tab Sheet

••

• Sheet Layout

When the "Password Set" tab is pressed, the following tab sheet ap-

pears.

Fig. 3E93 "Password Set" Tab Sheet

0206-002 5-104 AHB01EDTP

••

• Sheet Composition

*1 Supervisor

A password can be set in this group box for the user who has the

scope of authority as "Supervisor".

*2 Operator #1

A password can be set in this group box for the user who has the

scope of authority as "Operator #1".

*3 Operator #2

A password can be set in this group box for the user who has the

scope of authority as "Operator #2".

••

• How to set or change a password

(1) When the [Password Set] button is pressed according to the

given authority, the "Password Entry" edit window opens.

Fig. 3E94 "Password Entry" Edit Window

(2) Enter a password and press the [Set] button. the "Password Re-

entry" edit window opens. Enter the same password again and

press the [Set] button.

The password is set or changed and "Set" appears in red on the

right side of the [Password Set] button.

••

• How to cancel the set password

(1) To cancel the set password, press the [Password Set] button

according to the given authority. The "Password Entry" edit win-

dow opens.

4.2 "Password" Tab

0206-002 5-105 AHB01EDTP

(2) Press the [Set] button without entering any characters in the en-

try field. The "Password Reentry" edit window opens. Press the

[Set] button again without entering any characters.

The preset password is canceled and "Not Set" appears in blue

on the right side of the [Password Set] button.

4.2.2 "Available Area Set (1/2) or (2/2)" Tab Sheet

••

• Sheet Layout

When the "Available Area Set (1/2)" tab is pressed, the following tab

sheet appears.

Fig. 3E95 "Available Area Set (1/2)" Tab Sheet

••

• Sheet Composition

*1 "Available Area Set" Buttons

The labels on the buttons indicate that the functions described

on the left side of the buttons are available for the following op-

erators.

SUP: This indicates that only the supervisor is given the au-

thority to use the functions.

When a red bar appears on the right side of the

function name, it indicates that the function is avail-

able for "Supervisor".
