AHB01EDTP
2. "Selection of component ID" Window
2.1 Window Layout
This session describes how to open the "Selection of component ID"
window.
(1) Press the [DATA EDIT] button on the main menu bar. An "EDIT SEL."
menu opens.
Fig. 3C2 "EDIT SEL." Drop Down List
(2) Press the [CMPNT.LBRY.] button. The "Selection of component ID"
window opens.
Fig. 3C3 "Selection of component ID" Window
2.1 Window Layout
0308-004 3-2
AHB01EDTP
2.2 Composition of "Selection of component ID"
Window
This session describes the composition of the "Selection of compo-
nent ID" window.
Fig. 3C4 "Selection of component ID" Window
*1 Component shape, Component type
Select the desired component shape and type from the corresponding
combo boxes.
The component types corresponding to the selected shape and type
appear in "*7".
*2 Component ID
Displayed is the component ID selected in "*7".
*3 [Link ID Tree View] Button
Link and root IDs are arranged side by side and displayed in the
hierarchical (tree) file system.
*4 [Open], [Cancel], and [Type Addition] Buttons
[Open] Button
When pressed, this button opens the "Component Library" window
related to the component ID selected in "*7".
0308-003 3-3
*1
*2
*7
*8
*5
*6
*4
*3
2.2 Composition of "Selection of component ID" Window
AHB01EDTP
[Cancel] Button
When pressed, this button opens the "Component Library" window
without the selected component ID.
The "Close", "New", and "Open" icons become available in the "Com-
ponent Library" window.
[Type Addition] Button
Open the "Type Addition" dialog box to add a component type.
Refer to "2.3.1 Type Addition" for the detailed information on
the "Type Addition" dialog box (described later).
*5 [Close] Button (
)
When pressed, this button closes the "Selection of component
ID" window.
*6 Common Display and Standard ID Display
Select the desired option buttons.
Depending on which option buttons are selected, a list of compo-
nent IDs having specific attributes appears in "*7".
Option Buttons
: A dot inside the circle indicates that the corresponding func-
tion is selected.
When " " is pressed, it changes to " ".
: The corresponding function is not selected.
When "
" is pressed, it changes to " ".
*7 "List of Component IDs" Pane
A list of component IDs is displayed.
Select the component ID whose data should be displayed in the
"Component Library" edit window or the component ID to be de-
leted, copied, or renamed.
Component ID : Component IDs are displayed.
R:When "r" is set, it indicates that the compo-
nent ID is a root one.
C:When "c" is set, it indicates that the compo-
nent ID is registered as a common one.
P:When "p" is set, it indicates that the compo-
nent ID is protected.
S:When "s" is set, it indicates that the compo-
nent ID is a standard one.
0308-004 3-4
2.2 Composition of "Selection of component ID" Window
