2.1.5.2 "Stocker Mark" Tab

• Sheet Layout

When the "Stocker Mark" tab is pressed in the "Nozzle" tab sheet,

the following tab sheet appears.

Fig. 3E40 "Stocker Mark" Tab Sheet

• Sheet Composition

*1 Offset Items

Set the offset values of Marks #1 and #2 on Heads #1 and #2 for

each stocker (B1 and B2).

X [mm] (Horizontal) and Y [mm] (Vertical)

This offset data is used to adjust the positional deviations compared

with the design dimensions of the nozzle stocker unit positions

(viewed from the P.C.B. positioning reference X/Y coordinates (PL-

XY Coordinates: Origin P0)). The value based on the PL-XY coordi-

nate system must be entered in each text box.

The positional deviations based on the design values are calculated

through recognition operations on Marks #1 and #2 on the upper

surface of the nozzle stocker base.

0308-004 5-40

AHB01EDTP

2.1 "Offset Data" Tab

Fig. 3E41

0206-001 5-40-1

AHB01EDTP

2.1 "Offset Data" Tab

2.1.5.3 "Stocker B1" and "Stocker B2" Tabs

• Sheet Layout

When the "Stocker B1" tab is pressed in the "Nozzle" tab sheet, the

following tab sheet appears.

The navigations similar to those through the "Stocker B1" tab

sheet can be followed through the "Stocker B2" tab sheet.

Fig. 3E42 "Stocker B1" Tab Sheet

• Sheet Composition

*1 Offset Items

Set the following offset values.

Head (1 and 2) and Address (1 through 10)

X [mm] (Horizontal) and Y [mm] (Vertical)

This offset data is used to adjust the positional deviations based on

the design dimensions of the nozzle stocker unit positions (viewed

from the P.C.B. positioning reference X/Y coordinates (PL-XY Coor-

dinates: Origin P0)). The value based on the PL-XY coordinate sys-

tem must be entered in each text box.
