Sensor Detection Functions
4-5
LED is lighted. The case of no lighting indicates an unstable state.
Sensitivity is then adjusted with a PCB until the red and green LED's are lighted. The
case of only red LED lighted indicates an unstable state.
Figure 4-5. Sensor Adjustment
Warning
Adjusting the sensor or correcting an error while the
machine is ready could result in personal injury.
Be sure to adjust the sensor or correct an error in the stop
status (idle mode) after canceling the ready status.
Sensor Window
Green LED
Red LED
Sensitivity Adjusting Screw
Transfer & Installation Procedure
5-1
Chapter 5. Transfer & Installation
Procedure
Initial operation of this equipment should be performed according to the following
procedure.
1. Unpack the packing box.
2. M
ove the equipment to the intended location for installation. In case of using lift
truck(or lift cart), refer to lift arm size and usage direction.
Warning
If the machine is installed or test run by an untrained
person, the machine might be damaged and personal
injury could occur.
The installation or test run of machine must be carried out
by our authorized C/S personnel only.
Caution
If excessive force is exerted when the packaging is
removed, it could damage the cover of the machine.
Do not exert excessive force during the removal of
packaging.
Operational procedure
