Preparation for Production

6-1

Chapter 6. Preparation for Production

6.1. Preparation for the Component Supply Device

 Prepare for devices that supply components during the process such as tape feeder,

stick feeder, multi-tray feeder, etc. for the production board.

 Please refer to the manual of the corresponding component supply device for

guidance on installation.

6.2. ANC Preparation

A general 37-hole ANC is ed basic feature.

 If possible, use of the system ANC as set on the system is recommended.

6.3. PCB Conveyor Part

 Adjust the width of a conveyor. Preferably, the width of a conveyor should have the

margin of about 1mm each at the front and back when the board is inserted.

 I

n case of holding the board in place by using a hole fixer, select the PCB fixing pin of

the hole fixer tat matches the size of the hole in the board. The size of the fixing hole

in the board is carved on the processing side of the pin.

Caution

If the conveyor width is set too wide, the board may not be

fixed tightly when it is fixed with the edge fixer. Take

precautions.

Memo

Samsung Component Placer CP-45F(V)/FS Operations Manual

6-2

Figure 6-1. Replacement of the Fixing Pin of the Hole Fixer

After PCB is smoothly contacted to the ing stopper, adjust the position of the hole fixer

so that the pin of the hole fixer is accurately positioned onto the fixing hole of the board.

It is preferable to leave about 0.5 - 1.0mm space between the ing stopper and the side of

the board (in case of using the hole fixer for fixing).

Figure 6-2. Adjustment of the Hole Fixer Position

Warning

Adjusting the sensor or correcting an error while the

machine is ready could result in personal injury.

Be sure to adjust the sensor or correct an error in the stop

status after canceling the ready status.

1. Socket set screw 2. Socket head cap screw

Changing pin

Fixing pin

Sensor dog

Sensor

Preparation for Production

6-3

Caution

Unscrew one socket set screw of no.1 in the figure above

and adjust the position

As the 4 socket head cap screws of no. 2 are used to fix the

hole fixer on the conveyor, the hole fixer can not be fixed if

they are unscrewed.

They must not be unscrewed.
