Features and Scope of Equipment 1-1 1 1.5. Control System Specifications Embedded in the CP-45F/V and the CP-45FS is a high-speed CPU that provides the production and production management inform ation of PCB, and is des…
Samsung Component Placer CP-45F(V)/FS Operations Manual
1-10
Protect Module
1.4.3.2. Hardware
Windows 98
CPU Intel Celeron™ over 733MHz
Over 40GB of HDD, IDE
Hard Disk Rack
Over 64MB of memory
CD-ROM 48x
3.5 inch FDD lea
Keyboard: Mini Keyboard (86 keys)
Mouse: PS/2 mouse
1.4.3.3. Display
Programming Monitor: 14 inch VGA Color (1024 × 768 dots)
Teaching Monitor: 14 inch VGA Color (800 x 600 dot)
The specifications of the equipment can be altered without prior notice to improve the
product performance.
Memo
Features and Scope of Equipment
1-11
1.5. Control System Specifications
Embedded in the CP-45F/V and the CP-45FS is a high-speed CPU that provides the
production and production management information of PCB, and is designated for
creating and editing the production program as well. The system operation can reading be
learned by using the MMI based on Windows 98.
1.5.1. PCB production
Program selection
The CP-45F/V and the 45FS has large-capacity hard disk (over 10.2 GB). Data can
also be stored in a 3.5-inch floppy disk. The user can store the program or data either
in a hard disk or a floppy disk.
Continuous production of PCB
The number of completed PCB's produced is shown on the screen while PCB's are
being produced. The number of PCB's to be produced and the number of components
to be placed can be inputted, and the number of PCB's currently being produced on
the production management page can be shown on the screen.
Test driving functions
The correct coordinates of a component position can be obtained by temporarily
placing the component and inputting the correct coordinates through a teaching box
by tracking the position with a camera. In this case, the coordinates are adjusted
relative to each other.
Production management information
The CP-45F/V and the CP-45FS provides the following basic production
management information:
Number of completed PCB's
Operating time (actual running time)
Stop time
Number of successfully placed components
Number of bad-marked PCB's
Number of components supplied from each feeder
Samsung Component Placer CP-45F(V)/FS Operations Manual
1-12
1.5.2. Creation and editing of production program
The production program (Man-Machine Interface, MMI) is composed of the following
data parts:
PCB data: data related to PCB
Placement data: data on the components to be placed on PCB including their
positions (coordinates)
Component data: data related to the components
Feed data: data related to the feeder
Vision data: data related to vision recognition
Teaching
The pickups position or placement position can be inputted manually or by using a
teaching camera. For easy teaching of the pickups position or placement position by using
a camera, a cross-shaped cursor is provided on the teaching monitor screen.
1.5.3. I
nput/Output device
1.5.3.1. Keyboard
The CP-45F/V and the CP-45FS has keyboard on the upper position of the cover. They
are used for operating Window 98 and creating and editing data on MMI.
1.5.3.2. Teaching box
A teaching box is used for teaching the pickups position or placement position. The box
has a switch for selecting an object for teaching, X-Y control button, up-and-down
motion button along the Z-axis, and a rotation button. These switches and buttons are
Warning
During teaching, the operator or people near the operator
could be injured due to operation error or insufficient
checking of surroundings.
Before start teaching, check the device to teach one more
time, and check whether there is any worker near the
machine.
