Samsung Component Placer CP-45F(V)/FS Operations Manual
3-2
stage, power is not turned on for the drivers such as motor. The power should be
turned off only after terminating the MMI. If the power is suddenly turned off, the
data and the main body may be damaged and the equipment malfunction may occur
at the next power up.
<
M
a
in start> switch
Power is supplied by first pressing the green switch of a main start switch in order to
supply power to the power systems such as a motor. To cut off the power supply,
press the red switch.
<Ready> switch
This is a switch for initiating the operation of this equipment. The power is supplied
to the driving systems such as motor. It is used to put the equipment into the standby
status after power-up. <EMG (emergency stop)> switch can be pressed to release the
standby state.
<Start> switch
This is a switch for initiating the operation of this equipment. Automatic operation is
initiated if this switch is pressed.
This switch can be activated for the following cases:
Temporary stop status of operation by <Stop> switch during automatic operation.
Error stop status that can be restarted.
<Stop> switch
This is a switch for temporary stopping of the operation. Automatic operation of this
equipment is temporarily stopped if this switch is pressed. If this switch is pressed
while the placement is in progress, the operation is stopped after the present operation
is completed. This switch can also be used for turning off alarm sound due to an error.
<Reset> switch
Warning
If power supply is cut off suddenly, it could result in the
damage of data and machine.
And the machine might be damaged due to abnormal
operation when power is supplied again.
Before turning off power, be sure to end the MMI, turn
off the isolation switch, then turn on the isolation switch
after 5-10 seconds.
Panel Operations
3-3
This is a switch for terminating the operation of this equipment. Automatic operation
of this equipment is forcefully terminated if this switch is pressed. This switch is used
for deactivating either temporary stop status that had been activated by pressing the
<Stop> switch or the stop status due to an error. The <Reset> switch cannot be
activated during automatic operation of this equipment.
EMG (Emergency Stop) switch
This is an emergency stop switch. Operation of this equipment is immediately
suspended if this switch is pressed in case of an emergency. Supply of all powers
except for the power to a computer is ceased. The emergency stop status can be
released by turning the <EMG> switch in the direction of the arrow and pressing the
<Stop> and <Reset> switch.
Samsung Component Placer CP-45F(V)/FS Operations Manual
3-4
3.2. Standards for Lighting Signal Tower
This equipment comes with a signal tower for indicating the present status of the
equipment. The signal tower indicates the following:
Lighting of a red lamp
Indicates the stop status through self-diagnosis of the system. Warning sounds ring
continuously and messages are indicated as the red lamp is lighted.
Flashing of a red lamp
Indicates either the pressing of the <EMG> switch or the emergency stop status
through self-diagnosis of the system. Warning sounds ring continuously and
messages are indicated as the red lamp is flashed.
Lighting of a blue lamp
Indicates the standby status of operation.
Flashing of a blue lamp
Indicates either component shortage in the tray feeder or adsorption error. Warning
sounds ring continuously and messages are indicated as the yellow lamp is flashed.
Lighting of a green lamp
Indicates that this equipment is currently being operated automatically.
Flashing of a green lamp
Indicates temporary stop status. Automatic operation can be resumed by pressing the
<Start> switch.
Red
Blue
Green
Figure 3-2. Signal Tower
