Samsung Component Placer CP-45F(V)/FS Operations Manual
2-10
This installs a back-up pin for maintaining the evenness of a PCB, and drives the
PCB clamp, hole fixer, etc., prior to the beginning of work after the PCB has reached
the working position.
Caution
Be sure to remove any foreign substance on the BUT and
obstruction before manipulating the BUT.
Otherwise, the conveyor might be damaged.
Basic Configuration and Name of Each Part
2-11
2.7. Board Specifications
2.7.1. PCB sizes, allowable deflection error
PCB Sizes
Minimum
3-stage Conveyor: 50.0mm (x-axis) × 30.0mm (y-axis)
Maximum
460.0mm (x-axis) × 400.0mm (y-axis)
510.0mm (x-axis) x 460.0mm (y-axis) – Factory Option
PCB Thickness
Minimum
3-stage Conveyor: 0.38mm
Maximum: 4.0mm
Allowable deflection error
2.0mm (while fixed to the placement area)
Samsung Component Placer CP-45F(V)/FS Operations Manual
2-12
The sizes of PCB applicable for this equipment are as follows.
Front side conveyor fixed
Max: 460L×400W×4.2H [ mm ]
510.0mm (x-axis) x 460.0mm (y-axis) – Factory Option
Min: 50L×50W×0.38H [ mm ]
The maximum PCB size could differ according to the options.
20 stages Tray Feeder : 460 × 350 (2Tray / 1Pallet) , 460 × 400 (1Tray / 1Pallet)
24 stages Tray Feeder : 460 × 300 (1Tray / 1Pallet)
Rear side conveyor fixed
Max: 410L×360W×4.2H [ mm ]
Min: 50L×50W×0.38H [ mm ]
The maximum PCB size could differ according to the options.
20 stages Tray Feeder : 460 × 300 less
24 stages Tray Feeder : 460 × 270 less
2.7.2. PCB conveyor system height
Standard: 900.0mm ± 20.0mm
Semi-Standard: 952.50mm ± 12.5mm
For inquiries on PCB conveyor system height other than that listed above, please
contact our Business Department or C/S Center.
2.7.3. Conveyor rail width controller
Standard: Manual Control
Optional : Automation Control
2.7.4. Conveyor Regulator Pressure Setting
0.38t ~ 1.5t = 1.0kg / cm
2
(0.1Mpa)
1.5t ~ 4t = 2.0kg / cm
2
(0.1Mpa)
Note
