Item
Level the sensor.
Lead CheckerOptional Accessory Parts Replacement
28
Remove the iron plate from the head.
Allen key 3 mm
Screw M4 1 pc.
Iron plate for holding the
magnetic stand
Phillips screwdriver #2
Screw M4 2 pcs.
Put the NG box bracket back on.
Put the feeder cover back on.
30
31
Allen key 3 mm
Allen key 4 mm
Screw M4 x 10 3 PCs.
Thick washer 3 pcs.
Screw M5 2 pcs.
Put the chute back on.
See Section 4-1-9
"Lead Checker Height
Adjustment"
Remark
28
EJM8A-E-SMA060301-A01-00
Page 6-3-1-11
6 Option Accessory Parts
Replacement
(Component Height Control Device)
