This section describes the procedures for replacing the PCB-warp-sensor amplifier (8-nozzle head spec.) • Tools Phillips screwdriver #1 Phillips screwdriver #2 Allen key Long/short Pipe Nipper • Jigs PCB-Warp-Sensor Unit…
Remark
Component-Thickness-Measuring Unit
Item
Option Part and Accessory Replacement
Connect the amplifier connector.
Put the feeder cover back on.
Allen key 3 mm
Screw M4 4 pcs.
Turn on the power and air supply.
27
26
25
Amplifier connector
1
2
EJM8A-E-SMA060405-A01-00
Page 6-4-5-9
This section describes the procedures for replacing the PCB-warp-sensor amplifier (8-nozzle head spec.)
• Tools
Phillips screwdriver #1
Phillips screwdriver #2
Allen key Long/short
Pipe
Nipper
• Jigs
PCB-Warp-Sensor Unit
6-5-1 PCB-Warp-Sensor-Amplifier Replacement (8-Nozzle-Head Spec.)
Option Part and Accessory Replacement
PCB-Warp-Sensor Unit
6-5
Danger
Warning
Caution
EJM8A-E-SMA060501-A01-01 Page 6-5-1-1
Remarks
Turn off the power and air supply.
Remove the feeder cover.
Allen key 3 mm
Screw M4 4 pcs.
Remove the head upper cover.
Phillips screwdriver #2
Truss screw M4 4 pcs.
PCB-Warp-Sensor Unit
Item
1
2
3
4
Move the front and rear beams towards you.
Option Part and Accessory Replacement
1
2
Rear Front
EJM8A-E-SMA060501-A01-01
Page 6-5-1-2
