Tray Shuttle Tray 5 6 7 8 Lightly fix the sensor in place. Item Remarks Install a new sensor. Secure the cables with a cable tie. Mount the jig. Remove the sheet from the transfer unit. Switch on the power. Do not touch …
Disconnect the sensor connector.
3
4
2
1
Cut off the cable tie.
Remove the LED sensor.
Remove the top cover.
Phillips screwdriver #2
Allen key 3 mm
Screw M4 2 pcs.
M4 x 10L 8 pcs.
Nipper
Remarks
Allen key 2.5 mm
Screw M3 2 pcs.
Switch off the power.
Item
Shuttle TrayTray
EJM8A-E-SMA070116-A01-00
Page 7-1-16-2
Tray Shuttle Tray
5
6
7
8
Lightly fix the sensor in place.
Item Remarks
Install a new sensor.
Secure the cables with a cable tie.
Mount the jig.
Remove the sheet from the transfer unit.
Switch on the power.
Do not touch these
screws.
EJM8A-E-SMA070116-A01-00
Page 7-1-16-3
Shuttle TrayTray
10
11
12
heads.
Lower the pickup head.
Position the pickup and the transfer
Remarks
9
Fit the jigs on the pickup head.
Item
Press [Bst shutle pick up head1 down], [Bst shuttle pick up head2 down]
and [Bst shttle Tray spot ight].
9.5 mm from
mechanical
stopper
150.0 mm
from
mechanical
stopper
EJM8A-E-SMA070116-A01-00
Page 7-1-16-4
