Function Key Menu +PAGE : Press to display next screen -PAGE : Press to display previous screen ▲ : Press to move cursor up one device ▼ : Press to move cursor down one device ESC : Press to avoid checking all devices th…
As shown in the above figure there are 3 types of display modes for device check.
F1: MODE 1
In this mode the display screen will be the same as the one in the figure above where 10
consecutive device positions display whether the device position is used or not.
F2: MODE 2
In this mode the screen display will be like the one below where only the device
positions that are used in the program actually appear on the screen.
F3: MODE 3
In this mode the display screen will be like the one shown below. Among the device
positions that are used in the program, only those positions with a status condition such
as Un Set, Parts E, Pickup, Vision, etc. will actually display on the screen.
+PAGE -PAGE ▲▼ESC
CP643S2030
RETURN
D001
D002
D005
D006
D007
D009
D015
Un Set
Parts E
Vision
Tape E
Next_D
Pickup
Unset
[0013]
[0008]
[0001]
[0005]
[0007]
[0003]
[0023]
Device_comment_No1
Korewa_No_2_Desu
MSD2HD256
Micro_TR_No1
Super_Mini_TR
N3456Sd23
RECT3216060
Page 451
+PAGE -PAGE ▲▼ESC
RETURN
D001
D002
D003
D004
D005
D006
D007
D008
D009
D010
D015
Un Set
Parts E
Vision
Tape E
Next_D
Pickup
[0013]
[0008]
[0002]
[0000]
[0001]
[0005]
[0007]
[0002]
[0003]
[0015]
[0023]
Device_comment_No1
Korewa_No_2_Desu
PCPR102TL
MSD2HD256
Micro_TR_No1
Super_Mini_TR
Nihongonetute
N3456Sd23
Jaf
RECT3216060
Page 451
Unset
AB C D
Part 2 Chapter 1 Basic Operation
Edition 1.1 2-1-47 CP643E System Reference
Function Key Menu
+PAGE : Press to display next screen
-PAGE : Press to display previous screen
▲ : Press to move cursor up one device
▼ : Press to move cursor down one device
ESC : Press to avoid checking all devices that have not been checked yet.
However, if Proper data item 74: ESC Permission is not set to "Permit" this
key cannot be used.
The following methods can be used to register completion of device check.
1. Move the cursor to the appropriate page using the function keys and press the CR
key.
2. Input the device number.
[Example] device number 101
Input [1] [0] [1] and press the CR key to complete the check. The color of the display
will change to green. However, if the device number being input is not displayed on
the screen then only the screen will change. Device check completion is not
registered. The device number must be input again and the CR key pressed to register
that the check has been completed.
3. Press the [ESC] key.
This method allows the user to skip checking all devices that have not been checked.
However, if Proper data item 74: ESC Permission is not set to "Permit" this key cannot
be used.
+PAGE -PAGE ▲▼ESC
CP643S2031
RETURN
Part 2 Chapter 1 Basic Operation
Edition 1.1 2-1-48 CP643E System Reference
1.7.4 Permanent Set
If a number of production programs are being used, there are cases when frequently
used devices are fixed in order to eliminate several steps in the changeover process when
changing programs. When programs are changed, if this method is used, a comparison
is made between the device comments stored in present machine memory and the device
comment of the program that has changed. For any devices in common, device check is
omitted if the device has been checked already. Devices set in such a manner are
referred to as permanently set devices.
For example, consider the display below where production programs are carried out in
A → B → C order.
When changing from production program A to program B
If D1~D3 are used in both programs then once these devices have been checked they are
considered permanently set devices. These devices are displayed in green on the device
check screen.
Once a device check is completed on D7 it is considered a permanently set device. Since
D7 is not used in production program B a device check is not carried out. Permanently
set devices such as D7 that are not used in the current program display in blue on the
screen.
When changing from production program B to program C
D1 and D2 are used in both programs and have already been checked. These devices
have been judged as permanently set devices and are displayed in green on the device
check screen.
The device being used in D3 has changed and thus a device check is carried out. This
device is displayed in yellow on the device check screen until a check is carried out.
D7 has already been checked and determined as a permanently set device and thus it
displays in green.
Device_Comment
D1 RECT3216120
D2 RECT1608040
D3 MINI1220120
D4 ALEC4343570
D5 RECT2012040
D6 RNT45032040
D7 SQFP03610100
··········
Production program A
Device_Comment
D1 RECT3216120
D2 RECT1608040
D3 MINI1220120
D4 ALEC4343570
D5 RECT2012040
D6 RNT45032040
··········
Production program B
Device_Comment
D1 RECT3216120
D2 RECT1608040
D3 MINI1220120
D4 ALEC4343570
D5 RECT2012040
D6 RNT45032040
D7 SQFP03610100
··········
Production program C
Permanently Set Devices
CP643S2032
