ZOOM IN 522-1-4-1/522-3-1-2-1
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [ZOOM IN] / [SET]
- [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [DISPLAY] - [ZOOM IN]
This command magnifies the image that is displayed on the vision processing monitor. The image
is magnified further each time the function key is pressed. The maximum magnification rate is 128
times.
A magnified image can be used to verify a portion of an image that cannot be confirmed with the
focus and gray scale value per pixel of the normal monitor display.
Revision History
V1.10 and later
ZOOM OUT 522-1-4-2/522-3-1-2-2
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [ZOOM OUT]
/ [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [DISPLAY]
- [ZOOM OUT]
This command reduces the image that is displayed on the vision processing monitor. The image is
reduced further each time the function key is pressed. The maximum magnification rate is 1/128
times. This zooming out function can be used to return a magnified image to its original size or to
check the entire image.
Note: An image cannot be reduced further than the image size originally acquired by the CCD camera.
Revision History
V1.10 and later
SCROLL 522-1-4-4/522-3-1-2-4
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [SCROLL]
/[SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [DISPLAY]
- [SCROLL]
In the [SCROLL] command the direction of movement (up, down, left or right) changes each time
the function key is pressed. In the case of a magnified image, the [SCROLL] command can be used
to display one portion of the image in order to check that portion.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-53 CP643E System Reference
<<< 522-1-4-4-1
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [SCROLL] - [<<<]
This command will display the left portion of the image currently being displayed.
In other words, the image being displayed is moved to the right so that the left portion of the image
displays. Each time the function key is pressed the image will move by the number of pixels
specified using [STEP].
Revision History
V1.10 and later
>>> 522-1-4-4-2
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [SCROLL] - [>>>]
This command will display the right side portion of the image currently being displayed.
In other words, the image being displayed is moved to the left so that the right portion of the image
displays. Each time the function key is pressed the image will move by the number of pixels
specified using [STEP].
Revision History
V1.10 and later
▲ 522-1-4-4-3
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [SCROLL] - [▲]
This command will display the upper portion of the image currently being displayed.
In other words, the image being displayed is moved downward so that the upper portion of the
image displays. Each time the function key is pressed the image will move by the number of pixels
specified using [STEP].
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-54 CP643E System Reference
▼ 522-1-4-4-4
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [SCROLL] - [▼]
This command will display the lower portion of the image currently being displayed.
In other words, the image being displayed is moved upward so that the lower portion of the image
displays. Each time the function key is pressed the image will move by the number of pixels
specified using [STEP].
Revision History
V1.10 and later
STEP 522-1-4-4-5
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [SCROLL] - [STEP]
This command uses a number of pixels to specify the distance the display moves per step.
The number of pixels for each step setting changes as follows.
10 -> 25 -> 50 -> 100 -> 10 [pixel]
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-55 CP643E System Reference
