POSITION 2 531-4-2 Command Pass: [SET] - [PROPER] - [CAMERA] - [NARROW] - [POSITION 2] Press to display the "Press START" message which enables the Proper data measurement jig attached at the Station 6 vision p…
CHECK 531-3-4
Command Pass: [SET] - [PROPER] - [CAMERA] - [WIDE] - [CHECK]
This command enables the START button for carrying out measurement of the parts camera
(standard field of vision) resolution, X-direction tilt, Y-direction tilt, and angle of rotation.
If START is pressed after the [CHECK] command is pressed, measurement of the parts camera
(standard field of vision) resolution, X-direction tilt, Y-direction tilt, and angle of rotation will be
carried out.
Caution: Since the camera angle has a direct effect on placing accuracy, the camera should be installed and
adjusted so that it is at 0 degrees.
These values become machine Proper data. After Proper data measurement, always transmit the
Proper data from the machine to the host computer.
Revision History
NARROW 531-4-0
Command Pass: [SET] - [PROPER] - [CAMERA] - [NARROW]
Press to measure the resolution, tilt (X ,Y direction) and rotation of the narrow view parts camera.
Revision History
POSITION 1 531-4-1
Command Pass: [SET] - [PROPER] - [CAMERA] - [NARROW] - [POSITION 1]
Press to display the "Press START" message which enables the Proper data measurement jig
attached at Station 11 to move to the Station 6 vision processing.
When the START button is pressed the cam rotates backwards so that the Proper data measurement
jig attached to Station 11 moves to the Station 6 vision processing station.
After movement is completed, “POSITION2” and “CHECK” commands are displayed.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-85 CP643E System Reference
POSITION 2 531-4-2
Command Pass: [SET] - [PROPER] - [CAMERA] - [NARROW] - [POSITION 2]
Press to display the "Press START" message which enables the Proper data measurement jig
attached at the Station 6 vision processing station to move to Station 11.
If START is pressed after pressing [POSITION 2], the cam is rotated forward to move the Proper
data measurement jig at the Station 6 vision processing station to Station 11.
Caution: The camera should be adjusted so that the rotational orientation is as close as possible to 0° since
this orientation has a direct effect on placing accuracy.
The above values are machine Proper data settings and thus it is necessary to transmit Proper data
to the host computer once Proper data measurement is completed.
Revision History
CHECK 531-4-4
Command Pass: [SET] - [PROPER] - [CAMERA] - [NARROW] - [CHECK]
Press to display the "Press START" message which enables measurements to be carried out for the
parts camera resolution (with standard field of view), tilt in the X and Y direction, and rotational
orientation.
If START is pressed after pressing [CHECK], the parts camera resolution (with standard field of
view), tilt in the X and Y direction, and rotational orientation are measured.
Caution: The camera should be adjusted so that the rotational orientation is as close as possible to 0° since
this orientation has a direct effect on placing accuracy.
The above values are machine Proper data settings and thus it is necessary to transmit Proper data
to the host computer once Proper data measurement is completed.
Revision History
BRIGHT 531-5-0
Command Pass: [SET] - [PROPER] - [CAMERA] - [BRIGHT]
Press to set the gain or offset level for the parts camera and the mark camera.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-86 CP643E System Reference
MARK CAMERA 531-5-1
Command Pass: [SET] - [PROPER] - [CAMERA] - [BRIGHT] - [MARK CAMERA]
Press to set the mark camera gain and offset.
The desired level can be set either by entering a number using the numerical keypad, or by using
the function keys.
Caution: The gain and offset levels set here are machine Proper data settings and thus it is necessary to
transmit Proper data to the host computer once Proper data measurement is completed.
Revision History
▲ 531-5-1-1
Command Pass: [SET] - [PROPER] - [CAMERA] - [BRIGHT] - [MARK CAMERA] - [▲]
Press to change the gain or offset level by +1.
Caution: The gain and offset levels set here are machine Proper data settings and thus it is necessary to
transmit Proper data to the host computer once Proper data measurement is completed.
Revision History
■ 531-5-1-2
Command Pass: [SET] - [PROPER] - [CAMERA] - [BRIGHT] - [MARK CAMERA] - [■]
Press with ▲ or ▼ to change the gain or offset level in increments of 10.
Caution: The gain and offset levels set here are machine Proper data settings and thus it is necessary to
transmit Proper data to the host computer once Proper data measurement is completed.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-87 CP643E System Reference
