(1) Emergency Stop The following display appears when an emergency stop occurs. When a situation occurs in which the machine would be damaged if it continued to operate, the servo motors, conveyor motors and air cylinder…
Area B: Error Display Area
If an error occurs a message will display here.
Area C: Spare Device Status Display Area
In Device Change Mode, when the original table has been changed, the table not in use
acquires the status of spare device table.
Area D: Nozzle Skip Information Area
When a nozzle is skipped, the head of the skipped nozzles will display.
Area E: Tape End Information Area
This display indicates the device numbers of feeders which are about to run out of parts.
Once this situation is corrected the display disappears.
Display
Yellow
Red
Blue
Green
Meaning
Nozzle is skipped automatically based on statistical processing
(based on settings made at Proper data).
Nozzle is skipped based on nozzle center measurement errors.
Nozzle is skipped using command keys at the machine.
Nozzle is skipped based on nozzle assignment table at program.
CP643S1034
Display
D??? supply
D??? Check
D??? can't handle
Meaning
The device table named in the message has run short of parts.
The original table has been changed.
Parts could not be picked from the device table named in the
message.
Vision processing could not be carried out on the parts coming
from the device table named in the message. The original table
has been changed.
CP643S1033
Part 1 Chapter 1 Machine Overview
Edition 1.1 1-1-24 CP643E System Reference
(1) Emergency Stop
The following display appears when an emergency stop occurs.
When a situation occurs in which the machine would be damaged if it continued to
operate, the servo motors, conveyor motors and air cylinders stop operating. The
message “Waiting for Reset SW” appears, and after the problem is fixed, the RESET
button should be pressed. The message “Ready” will then appear.
CP643S1036
Emergency Stop
Waiting for Reset SW
The safety door (front) or
conveyor cover is open.
1ABC
2ABCDE
3K
4BCD
5HIJ
6OP
000
000
000
000
000
000
Skip Nozzle Tape End
CP643S1035
Part 1 Chapter 1 Machine Overview
Edition 1.1 1-1-25 CP643E System Reference
(2) Cycle Stop (During Automatic Operation)
The following display appears when a cycle stop occurs.
A cycle stop occurs when an error which interrupts automatic operation has occurred
(except for the case where the CYCLE STOP switch is pressed). The machine continues
the operation until it can safely stop and the message “Waiting for Reset SW” appears
along with a brief description of the error on the machine. After the source of the
problem has been removed, press the RESET switch, and the “Press START” message
will appear.
CP643S1038
Waiting for Reset SW
D100 Resupply
1ABC
2EFG
3LMN
4OPQ
5HIJK
6AT
000
000
000
000
000
000
Skip Nozzle Tape End
CP643S1037
Part 1 Chapter 1 Machine Overview
Edition 1.1 1-1-26 CP643E System Reference
