Zmin 535-4-0
Command Pass: [SET] - [PROPER] - [Z] - [Zmin]
This sets the Z-axis negative direction Proper data item.
Revision History
V1.10 and later
M_load_pos 535-5-0
Command Pass: [SET] - [PROPER] - [Z] - [M_load_pos]
This sets the “M_load_pos” Proper data.
Revision History
V1.10 and later
SERVO 540-0-0
Command Pass: [SET] - [SERVO]
Press to set servo parameters.
The servo counter is automatically displayed when the command [SERVO] is selected.
Caution : Holding down the inching shift key ([F]) while pressing RETURN will cause the servo counter display
to remain on the monitor.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-102 CP643E System Reference
SPEED 541-0-0
Command Pass: [SET] - [SERVO] - [SPEED]
Press to change the inching speed.
The inching speed can be entered in a range of 1 - 5 to change the slow inching speed of an axis.
A larger number will speed up the inching speed.
After the power is cut these changes are retained in memory.
Revision History
▲ 541-1-0
Command Pass: [SET] - [SERVO] - [SPEED] - [▲]
Press to move the cursor up one line to the servo axis to be changed.
Revision History
▼ 541-2-0
Command Pass: [SET] - [SERVO] - [SPEED] - [▼]
Press to move the cursor down one line to the servo axis to be changed.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-103 CP643E System Reference
CONV WIDTH (Displayed for HELPS) 542-0-0
Command Pass: [SET] - [SERVO] - [CONV WIDTH]
Press to set or change the conveyor width.
This function key is effective only when the machine is set to automatically adjust conveyor width.
The current conveyor width is displayed in increments of 0.01 mm.
Using the [↑] and [↓] keys the conveyor width can be changed.
Also, the width can be entered in 0.01 mm increments using the numerical keypad.
Calibrate the current conveyor width and input in increments of 0.01 mm. However, input is only
possible in a range from the minimum PCB width to the maximum PCB width.
Revision History
TRACE LIST 544-0-0
Command Pass: [SET] - [SERVO] - [TRACE LIST]
This command is used to display the status of servo boards.
Caution: This command is used for debugging and should not be entered by the user.
Revision History
COMMON AREA SVR
Command Pass: [SET] - [SERVO] - [TRACE LIST] - [COMMON AREA]
This displays the data found in the common area of all servo boards.
Input the desired board number or axis number using the numeric keypad.
This determines which servo board (or axis) data is to be displayed.
Caution: This command is used for debugging and should not be entered by the user.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-104 CP643E System Reference
